Fractal Design Era 2 Gaming Computer Case FDCERA2N01

This item is brand-new, factory sealed.

COMPUTER CASE
Era 2
Era 2 is an evolution of our iconic small form factor case - melding design innovation with engineering prowess.
Elegance in
every detail
Iconic design
Enjoy a sleek, sculpted aesthetic complete with an anodized aluminum exterior and an FSC-certified walnut top panel.
Streamlined gaming
Install a graphics card up to 326 mm in length and pair it with a radiator up to 280 mm (240 recommended) for powerful SFF gaming.
Ventilated performance
Features ample ventilation engineered to direct airflow through the case and includes two Aspect 12 PWM fans.
Smooth access
Enjoy tool-free access with a magnetic top panel, an exterior which slides off and a push-to-release top bracket.
Flexible interior
Adapt your build towards CPU cooling space or graphics card width with a slidable central wall offering 15 mm of flexibility.
Ready to connect
Includes a PCIe 4.0 riser cable pre-installed in the case and features dedicated mounts for up to four 2.5 drives.
Front-facing I/O
Features an illuminated power button and two USB ports for connecting devices, including one USB Type-C 20Gbps.Specifications
3.5"/2.5" drive mounts
0 total, 0 included
Dedicated 2.5" drive mounts
4 total, 4 included (2 on motherboard wall)
5.25 drive mounts
0 total, 0 included
Expansion slots
3
Motherboard compatibility
ITX
Power supply type
SFX / SFX-L
Front interface
1 x USB 3.2 Gen 2x2 Type-C, 2 x USB 3.0, Audio
Total fan mounts
4 x 120 or 2 x 120 and 2 x 140 mm (2x120 mm Aspect PWM fans included)
Top fan
2 x 120 mm or 2 x 140
Bottom fan
2 x 120 mm
Dust filters
Bottom
Top radiator
Up to 315 x 140 mm with total thickness less than or equal 52 mm
Up to 300 x 140 mm with total thickness less than or equal 58 mm
GPU max length
326 mm
GPU max Height
137 mm
GPU max thickness
48-63 mm (depending on motherboard wall position)
CPU cooler max height
55-70 mm (depending on motherboard wall position)
Cable routing grommets
No
Fixed cable straps
Yes (2 included)
Captive thumbscrews
PCI-e Blanks
Panels
Aluminum
SFF-Ready Enthusiast GeForce Cards
Yes
Note
If you wish to use the Era 2 PCIe 4.0 riser cable together with a PCIe 5.0 compatible motherboard and graphics card, make sure you first set the PCIe Slot Configuration in your motherboard BIOS or UEFI to PCIe Gen4 for best system stability.Other
Package contents
Case, Accessory Box, Designers Letter, Quick Start Note
Accessory box contents
SSD Screw x16, PSU Screw x4, Motherboard Screw x8, Zip Tie x4Item Dimension (L"xW"xH")
18 x 10 x 17

Weight
23 lbs

Warranty Information
2 Years
