Fractal Design FDCMES3X05 Meshify 3 XL Ambience Pro RGB Computer Case
(No reviews yet)
Write a Review
- SKU:
- 21102429
- MPN:
- fd-c-mes3x-05
- Availability:
- Usually ships the same or next business day.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 04/20/2026 08:10:49 PM PST
- Stock Update:
- 04/20/2026 08:10:49 PM PST
Description
This item is brand-new, factory sealed.
COMPUTER CASEMeshify 3 XL
Experience advanced cooling and expressive, aerodynamic design in a spacious format. An evolution of our mesh performance series, Meshify 3 XL offers performance-boosting engineering upgrades, three powerful Momentum fans, and next-level atmospheric lighting in Ambience Pro RGB versions.
Enhanced performance in a generous format
Advanced airflow
Access performance engineering in a spacious format, with ample ventilation and an air guide which helps keep components running cool.
Evolved design
Elevate your space with an aerodynamic design aesthetic featuring a sleek, rockface-inspired mesh front panel.
Designed for gaming
Create a powerful gaming system with space for graphics cards up to 512 mm in length and E-ATX (330 mm) motherboard compatibility.
Ambience Pro RGB Version
Enhanced lighting
Create the right atmosphere with advanced ARGB Gen 2 ambient lighting, including an animated PC startup effect.Specifications
3.5"/2.5" drive mounts
2/4
Dedicated 2.5" drive mounts
1
5.25 drive mounts
-
Expansion slots
7
Adjust Pro Hub
Included in Ambience Pro RGB version
Ambience Case Lighting
Ambience Pro RGB version
Front interface
1 x USB Type-C 20 Gbps, 2 x USB Type-A 5 Gbps, 1x Audio Combo Jack, Power button
Total fan mounts
10 (140 mm) / 7 (120 mm)
Front fan
3x 120/140 mm, 2x 180 mm (3 x 140 mm Momentum Included)
Top fan
3x 120/140 mm
Rear fan
1x 120/140 mm
Bottom fan
-
Side fan
3x 140 mm (no 120 support without radiator)
Dust filters
PSU (Bottom)
Cable routing space
37.5 mm
Cable cover
Yes
Cable organizers
3 Hook-and-loop straps + 3 Cable Aligners
Tool-less push-to-lock
Both Side Panels, Bottom Filter, Front Panel, Top Panel
Captive thumbscrews
Top Radiator Bracket, Air Guide, PSU Bracket
Left side panel
Industrial steel (Solid), Tempered Glass (TG/RGB/Ambience Pro RGB)
Right side panel
Industrial steelCompatibility
Power supply type
ATX
Motherboard compatibility
E-ATX (330 mm) / ATX / mATX / ITX / EE-ATX / SSI-EEB / SSI-CEB
PSU max length
230 mm
GPU max length
512 mm
GPU max height
189 mm (7 slot) including cables
CPU cooler max height
182 mm
Front radiator
280/360 mm
Top radiator
360/420 (up to 475) mm
Rear radiator
Up to 120/140 mm
Side radiator
360 mm (with brackets)Other
Package contents
Case, Accessory Box, Manual, Red Note
Accessory Box content (Ambience Pro RGB)
PSU Screws x4, MB Screws x12, SSD screws M3 x20, Zip tie x5, HDD rubber x8, MB standoff x4, HDD screws x8, 500 mm Fractal Connect Cable x1, Legacy Splitter CableItem Dimension (L"xW"xH")
28 x 14 x 24
Weight
68 lbs
Warranty Information
2 years
Features
Package Contents:
- Computer Case Meshify 3 XL
- Manual
- Red Note
- Accessory Box (4 x PSU Screws, 12 x MB Screws, 20 x SSD Screws M3, 5 x Zip Tie, 8 x HDD Rubber, 4 x MB Standoff, 8 x HDD Screws, 1 x 500 mm Fractal Connect Cable, Legacy Splitter Cable)
Specs
| Power Description | |
| Power Supply Installed | No |
| Physical Characteristics | |
| Product Material |
|
| Form Factor | Full-tower |
| Weight (Approximate) | 25.13 lb |
| Cooler Type | Fan/Liquid Cooler |
| Product Color |
|
| Height | 20.3" |
| Color Family | White |
| Maximum GPU Length | 20.16" |
| Maximum PSU Length | 9.06" |
| Width | 9.6" |
| Depth | 22.6" |
| Maximum CPU Cooler Height | 7.17" |
| Warranty | |
| Limited Warranty | 2 Year |
| I/O Expansions | |
| Total Number of Expansion Slots | 7 |
| Interfaces/Ports | |
| Headphone/Microphone Combo Port | Yes |
| Microphone | Yes |
| Total Number of Audio Out Ports | 1 |
| USB Port Details |
|
| Front Audio In | Yes |
| Front Audio Out | Yes |
| Front USB | Yes |
| Total Number of USB Ports | 3 |
| Total Number of Audio In Ports | 1 |
| Bays | |
| Number of Internal 2.5" Bays | 4 |
| Number of Total Expansion Bays | 6 |
| Number of Internal 3.5" Bays | 2 |
| General Information | |
| Brand Name | Fractal Design |
| Package Type | Retail |
| Manufacturer Website Address | http://www.fractal-design.com |
| Marketing Information | Enhanced performance in a generous format Advanced airflow Access performance engineering in a spacious format, with ample ventilation and an air guide which helps keep components running cool. Evolved design Elevate your space with an aerodynamic design aesthetic featuring a sleek, rockface-inspired mesh front panel. White Black Designed for gaming Create a powerful gaming system with space for graphics cards up to 512 mm in length and E-ATX (330 mm) motherboard compatibility. Ambience Pro RGB Version Enhanced lighting Create the right atmosphere with advanced ARGB Gen 2 ambient lighting, including an animated PC startup effect. Ambience Pro RGB Version Tailored experience Customize your lighting and fans easily with a download-free configuration tool, accessed via the included Adjust Pro Hub. Easily accessible Enjoy a smooth build experience with easily removable panels, including a sliding top panel featuring a fabric tab. |
| Product Type | Gaming Computer Case |
| Product Name | Computer Case Meshify 3 XL |
| Manufacturer | Fractal Design |
| Manufacturer Part Number | FD-C-MES3X-05 |
| Product Line | Meshify 3 XL |
| Technical Information | |
| Motherboard Supported |
|
| Installed Fan Size | 5.51" |
| Installed Fan Size Details | 3 ? 140mm |
| Fan Supported Details | <p><b>Front Fan:</b></p><ul><li>3 x 120/140 mm, 2x 180 mm (3 x 140 mm Momentum Included)</li></ul><p><b>Top Fan:</b></p><ul><li>3 x 120/140 mm</li></ul><p><b>Rear Fan:</b></p><ul><li>1 x 120/140 mm</li></ul> |
| Window Panel Location | Left Side |
| Number of Fans Supported | 10 |
| Features | Dust Filter |
| Window Panel | Yes |
| Fan Size Supported |
|
| Number of Fans Installed | 3 |
