Fractal Design Case FD-CA-MESH-C-MINI-BKO-TGD Meshify C Mini Dark Tempered Glass mATX/ITX

(No reviews yet) Write a Review
Usually ships the same or next business day.
Calculated at Checkout
Stock Update:
06/01/2023 03:35:47 PM PST
  • Main
  • Right
  • Rear
  • Left
  • Front
  • Alternate-Image9
  • Alternate-Image8
  • Alternate-Image7
  • Alternate-Image6
  • Alternate-Image5
  • Alternate-Image4
  • Alternate-Image3
  • Alternate-Image21
  • Alternate-Image20
  • Alternate-Image2
  • Alternate-Image19
  • Alternate-Image18
  • Alternate-Image17
  • Alternate-Image16
  • Alternate-Image15
  • Alternate-Image14
  • Alternate-Image13
  • Alternate-Image12
  • Alternate-Image11
  • Alternate-Image10
  • Alternate-Image1
Stock Update:
06/01/2023 03:35:47 PM PST


This item is brand-new, factory sealed.


  • Mfr Part Number:FD-CA-MESH-C-MINI-BKO-TGD
  • Features:
    • Streamlined high-airflow design
    • The performance and capacity of a larger tower in a remarkably compact mATX designed tower
    • Angular mesh front panel maximizes air intake
    • Tinted tempered glass side panel for a clean looking exterior with full interior visibility
    • Distinctive styling with stealthy black-on-black aesthetic
    • Flexible storage options with room for up to 5 drives
    • Sturdy steel drive trays with vibration-dampening rubber grommets cushion hard drives for smooth, quiet and reliable operation
    • Two preinstalled Fractal Design Dynamic X2 GP-12 120 mm fans deliver optimum airflow with minimal noise
    • Open interior layout creates an unobstructed airflow path from front intake to rear exhaust
    • Easy-to-clean filters on the front, top and base with full PSU coverage and convenient front access
    • Full length power supply shroud conceals drive cage and excess cabling for unrestricted airflow and a clean looking interior
    • Up to 35 mm of space behind motherboard plate with grommeted pass-throughs for clean cable routing
  • Case Type:MicroATX Case
  • Material: N/A
  • M/B Type: MicroATX, ITX
  • Drive Bays:
    • Internal Bays: 2x 3.5" or 2.5" , 3xDedicated 2.5"
  • Expansion Slots: 5
  • Cooling System:
    • Front:3x 120 or2x 140mm Fan Vents (1xDynamic X2 GP-12Fan is included)
    • Top:2x 120/140mm Fan Vents (Fans not included)
    • Rear:1x 120mm Fan (1xDynamic X2 GP-12Fan is included)
    • Bottom:1x 120mm Fan Vent(Fannot included)
    • Dust filters:Bottom fan + PSU Front fans Top fans
    • Radiator:
      • Front:120/240mm 140/280mm (max width 144mm)
      • Top:120/240mm (max component height on motherboard 40 mm)
      • Rear:120mm (max width 125mm)
  • Side Windows: Yes
  • Maximum Compatibility:
    • VGA Card Length: 315mm (w/ front fans mounted)
    • CPU Cooler Height: 172mm
    • Cable Routing:15- 35 mm
  • ?Power Supply: None, 175mm Max ATX PSU Length
  • Dimensions (WxLxH): 212.0 x 395.0 x 399.0 mm
  • Weight: 6.28kg

Package Contents:
  • Meshify C Mini - Dark TG Computer Case
  • User Manual
  • Accessory Box
  • Top Filter


Package Contents:
  • Meshify C Mini - Dark TG Computer Case
  • User Manual
  • Accessory Box
  • Top Filter



Power Description
Power Supply InstalledNo
Number of Power Supplies Supported1
Number of Power Supplies Installed0
Physical Characteristics
Product Material
Form FactorMid-tower
Weight (Approximate)13.85 lb
Product ColorBlack
Maximum PSU Length6.89"
Maximum CPU Cooler Height6.77"
Limited Warranty2 Year
I/O Expansions
Number of Total Expansion Slots5
Total Number of Audio Out Ports1
Front Audio InYes
Front Audio OutYes
Front USBYes
Total Number of USB Ports2
Total Number of Audio In Ports1
Number of Internal 2.5" Bays3
Number of Total Expansion Bays5
Number of Internal 2.5"/3.5" Bays2
General Information
Brand NameFractal Design
Manufacturer Website Address
Marketing InformationMeshify strikes an aggressive pose in the Fractal Design lineup with unparalleled cooling performance and a defiant new look. Like black diamond facets, the angular asymmetry of the Meshify C carves a space uniquely its own as a new force in high-airflow design.;
An open ATX layout with intelligent space utilization creates an unrestricted airflow path from the mesh front intakes directly through key components to exhaust, ensuring heat is never an issue. The Meshify C has a remarkably compact footprint with the high-end component support of a larger tower, and with seven fan mounts and multi-radiator liquid cooling capability, it has the cooling capacity to match.
When performance is top priority and compromise is not an option, Meshify has you covered in style.
Product TypeComputer Case
Product NameMeshify C Mini - Dark TG Computer Case
ManufacturerFractal Design
Manufacturer Part NumberFD-CA-MESH-C-MINI-BKO-TGD
Product LineMeshify C
Technical Information
Motherboard Supported
Installed Fan Size4.72"
Number of Fans Supported7
Number of Fans Installed4
