Gigabyte Technology
Gigabyte Ultra Durable H610M S2H V2 DDR4 [rev. 1.0] Desktop Motherboard - Intel H610 Chipset - Socket LGA-1700 - Intel Optane Memory Ready - Micro ATX (h610ms2hv2ddr4)
(No reviews yet)
Write a Review
- SKU:
- 20063877
- MPN:
- h610ms2hv2ddr4
- Availability:
- Usually ships the same or next business day.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 12/13/2025 01:11:46 PM PST
- Stock Update:
- 12/13/2025 01:11:46 PM PST
Description
This item is brand-new, factory sealed.
Intel H610 Motherboard with 6+1+1 Hybrid Phases Digital VRM Design, PCIe 4.0* Design, Gen3 x4 M.2, DisplayPort / HDMI / DVI-D/ D-Sub Ports for Multiple Display , Anti-Sulfur Resistor, Smart Fan 6Supports Intel Core 14th/ 13th /12th processors
Dual Channel Non-ECC Unbuffered DDR4, 2 DIMMs
6+1+1 Hybrid Digital VRM Design
GbE LAN with Bandwidth Management
NVMe PCIe 3.0 x4 M.2
DisplayPort / HDMI / DVI-D / D-Sub Ports for Multiple Display
High Quality Audio Capacitors and Audio Noise Guard
Smart Fan 6 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP
GIGABYTE APP Center, Simple and Easy Use
Anti-Sulfur Resistors DesignCPU
1.LGA1700 socket: Support for the 14th, 13th, and 12th Generation
Intel CoreTM, Pentium Gold and Celeron Processors1
2.L3 cache varies with CPU
1 Please refer to "CPU Support List" for more information.
Chipset
1.Intel H610 Express Chipset
Memory
1.Support for DDR4 3200/3000/2933/2666/2400/2133 MT/s memory modules
2.2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory
3.Dual channel memory architecture
4.Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
5.Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
6.upport for Extreme Memory Profile (XMP) memory modules
(Please refer "Memory Support List" for more information.)Onboard Graphics
Integrated Graphics Processor-Intel HD Graphics support:
1.1 x D-Sub port, supporting a maximum resolution of 1920x1200 at 60 Hz
2.1 x DVI-D port, supporting a maximum resolution of 1920x1200 at 60 Hz
(The DVI-D port does not support D-Sub connection by adapter.)
3.1 x HDMI port, supporting a maximum resolution of 4096x2160 at 60 Hz
(Support for HDMI 2.0 version and HDCP 2.3.)
4.1 x DisplayPort, supporting a maximum resolution of 4096x2304 at 60 Hz
(Support for DisplayPort 1.2 version and HDCP 2.3)
(Graphics specifications may vary depending on CPU support.)Audio
1.Realtek Audio CODEC
2.High Definition Audio
3.2/4/5.1/7.1-channel
(You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.)
LAN
1.Realtek GbE LAN chip (1 Gbps/100 Mbps)
Expansion Slots
CPU:
1.1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16
Chipset:
2.1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1
Storage Interface
Chipset:
1.1 x M.2 connector (Socket 3, M key, type 2280/2260 PCIe 3.0 x4/x2 SSD support)
2.4 x SATA 6Gb/s connectors
USB
Chipset:
1.4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
2.4 x USB 2.0/1.1 ports on the back panel
Chipset+USB 2.0 Hub:
3.4 x USB 2.0/1.1 ports available through the internal USB headersInternal I/O Connectors
1.1 x 24-pin ATX main power connector
2.1 x 8-pin ATX 12V power connector
3.1 x CPU fan header
4.2 x system fan headers
5.1 x M.2 Socket 3 connector
6.4 x SATA 6Gb/s connectors
7.1 x RGB LED strip header
8.1 x front panel header
9.1 x front panel audio header
10.1 x USB 3.2 Gen 1 header
11.2 x USB 2.0/1.1 headers
12.1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
13.1 x serial port header
14.1 x Clear CMOS jumperBack Panel Connectors
1.1 x PS/2 keyboard port
2.1 x PS/2 mouse port
3.1 x D-Sub port
4.1 x DVI-D port
5.1 x DisplayPort
6.1 x HDMI port
7.2 x USB 3.2 Gen 1 ports
8.4 x USB 2.0/1.1 ports
9.1 x RJ-45 port
10.3 x audio jacksI/O Controller
1.iTE I/O Controller Chip
H/W Monitoring
1.Voltage detection
2.Temperature detection
3.Fan speed detection
4.Water cooling flow rate detection
5.Fan fail warning
6.Fan speed control
(Whether the fan speed control function is supported will depend on the cooler you install.)
BIOS
1.1 x 128 Mbit flash
2.Use of licensed AMI UEFI BIOS
3.PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0Unique Features
1.Support for APP Center
(Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.)
at BIOS
Ambient LED
EasyTune
Smart Backup
System Information Viewer
2.Support for Q-Flash
3.Support for Xpress Install
Bundled Software
1.Norton Internet Security (OEM version)
2.LAN bandwidth management software
Operating System
1.Support for Windows 11 64-bit
2.Support for Windows 10 64-bit
Form Factor
1.Micro ATX Form Factor 23.0cm x 21.5cmItem Dimension (L inchxW inchxH inch)
11 x 11 x 3
Weight
3 lbs
Warranty Information
3 Years
Features
Environmentally Friendly:
Yes
Energy-related Products Directive Ready (ErP Ready)
Yes
Energy Efficiency Compliance:
Energy-related Products Directive Ready (ErP Ready)
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Waste Electrical and Electronic Equipment Directive (WEEE)
Specs
| Physical Characteristics | |
| Form Factor | Micro ATX |
| Width | 9.1" |
| Depth | 8.5" |
| I/O Expansions | |
| Number of PCI Express x1 Slots | 1 |
| Total Number of Expansion Slots | 2 |
| PCI Express Standard |
|
| Number of PCI Express x16 Slots | 1 |
| Total Number of PCI Express Slots | 2 |
| Memory | |
| Memory Technology | DDR4 SDRAM |
| Number of Memory Slots | 2 |
| Memory Speed Supported |
|
| Memory Form Factor |
|
| Maximum Memory Supported | 64 GB |
| Intel Optane Memory Ready | Yes |
| General Information | |
| Brand Name | GIGABYTE |
| Manufacturer Website Address | http://www.gigabyte.us |
| Marketing Information | Cleaner and more efficient power delivery to the CPU with better thermal performance ensure stability under high CPU frequencies and heavy loading. 6+1+1 Phases Low RDS(on) MOSFETs Solid capacitors to improve transient response and minimize oscillation. 8-pin Solid Pin CPU Power Connector. GbE LAN with Bandwidth Management GbE LAN features a network bandwidth management application which helps to improve network latency and maintain low ping times to deliver better responsiveness in crowded LAN environments. Solid Pin Power Connectors H610 motherboards feature solid plated ATX 12V 8pin power connectors to offer a stable power supply during CPU overloading. Solid Pin Power connector advantages Larger contact area for electricity More metal quantity to sustain higher power and generated heat Ultra durable and longer lifespan BIOS The BIOS is essential for users during initial setup to allow for the most optimal settings. With a new GUI and easier to use functionalities, GIGABYTE has been able to reinvent the BIOS to give users a better experience while setting up their new system. |
| Product Type | Desktop Motherboard |
| Product Name | Ultra Durable H610M S2H V2 DDR4 (rev. 1.0) Gaming Desktop Motherboard |
| Manufacturer | GIGABYTE Technology, Inc |
| Manufacturer Part Number | H610MS2HV2DDR4 |
| Product Model | H610M S2H V2 DDR4 (rev. 1.0) |
| Product Line | Ultra Durable |
| Processor & Chipset | |
| Chipset Manufacturer | Intel |
| Processor Generation Supported |
|
| Processor Supported |
|
| Total Processor Supported | 1 |
| Processor Socket | Socket LGA-1700 |
| Chipset Model | H610 |
| Onboard Interfaces | |
| Number of SATA Interfaces | 4 |
| Total Number of Onboard USB Ports | 6 |
| Number of Onboard USB 3.2 Ports | 2 |
| Number of M.2 Interfaces | 1 |
| Number of Onboard USB 2.0 Ports | 4 |
| Interfaces/Ports | |
| HDMI Version | <li>2.0</li> |
| DisplayPort | Yes |
| DVI | Yes |
| HDMI | Yes |
| Number of USB 2.0 Ports | 4 |
| Total Number of USB Ports | 6 |
| Number of USB 3.2 Gen 1 Ports | 2 |
| Number of Network (RJ-45) Ports | 1 |
| I/O Controller | |
| Controller Type | Serial ATA/600 |
| Video | |
| Onboard Video | CPU Dependent Video |
| Network & Communication | |
| Gigabit Ethernet | Yes |
| Audio | |
| Audio Channels | 7.1 |
Warranty Information
All Items are Brand New, Factory Sealed and come with a standard warranty. [Read our policies]
View AllClose
Gigabyte Ultra Durable H610M S2H V2 DDR4 [rev. 1.0] Desktop Motherboard - Intel H610 Chipset - Socket LGA-1700 - Intel Optane Memory Ready - Micro ATX (h610ms2hv2ddr4)
$122.99
