Intel
SOLIDIGM D3-S4520 1.92 TB Solid State Drive - 2.5" Internal - SATA [SATA/600] (ssdsc2kb019tz01)
(No reviews yet)
Write a Review
- SKU:
- 18350717
- MPN:
- ssdsc2kb019tz01
- Availability:
- Out of stock
- Stock Update:
- 09/25/2025 04:27:00 PM PST
- Stock Update:
- 09/25/2025 04:27:00 PM PST
Description
This item is brand-new, factory sealed.
Solidigm SSD SSDSC2KB019TZ01 D3-S4520 1.92TB 2.5" SATA 6Gb/s 3D4 TLC RetailEssentialsProduct Collection
Intel SSD D3 Series
Code Name
Products formerly Youngsville Refresh Refresh
Capacity
1.92 TB
Lithography Type
144L TLC 3D NAND
Use Conditions
Server/EnterprisePerformance Specifications
Sequential Bandwidth - 100% Read (up to)
550 MB/s
Sequential Bandwidth - 100% Write (up to)
510 MB/s
Random Read (100% Span)
91000 IOPS (4K Blocks)
Random Write (100% Span)
38000 MB/s (4K Blocks)
Power - Active
3.1W
Power - Idle
1.1WReliability
Vibration - Operating
2.17 GRMS (5 - 700 Hz) Max
Vibration - Non-Operating
3.13 GRMS (5 - 800 Hz) Max
Shock (Operating and Non-Operating)
1,000 G (Max) at 0.5 msec
Operating Temperature Range
0oC to 70oC
Operating Temperature (Maximum)
70 oC
Operating Temperature (Minimum)
0 oC
Endurance Rating (Lifetime Writes)
8.8 PBW
Mean Time Between Failures (MTBF)
2 million hours
Uncorrectable Bit Error Rate (UBER)
less than 1 sector per 1017 bits readPackage Specifications
Form Factor
2.5" 7mm
Interface
SATA 3.0 6Gb/SAdvanced Technologies
Enhanced Power Loss Data Protection
Yes
Hardware Encryption
AES 256 bit
Temperature Monitoring and Logging
Yes
End-to-End Data Protection
YesItem Dimension (L"xW"xH")
17 x 13 x 6
Weight
9 lbs
Warranty Information
5 Years
Features
Device Supported:
Server
Server
Specs
| Physical Characteristics | |
| Form Factor | 2.5" |
| Drive Type | Internal |
| Height | 0.3" |
| Warranty | |
| Limited Warranty | 5 Year |
| Interfaces/Ports | |
| Drive Interface Standard | SATA/600 |
| Drive Interface | SATA |
| General Information | |
| Brand Name | SOLIDIGM |
| Package Type | Bulk |
| Manufacturer Website Address | http://www.solidigm.com |
| Marketing Information | Standard-endurance SATA drives with capacities up to 7.68 TB, designed to increase server efficiency and boost IOPS/TB performance over legacy hard disk drives (HDDs) for cloud storage. |
| Product Type | Solid State Drive |
| Product Name | SSD D3-S4520 Series (1.92TB, 2.5in SATA 6Gb/s, 3D4, TLC) |
| Manufacturer | SOLIDIGM |
| Manufacturer Part Number | SSDSC2KB019TZ01 |
| Product Series | D3-S4520 |
| Packaged Quantity | 1 |
| Drive Performance | |
| Maximum Read Transfer Rate | 550 MB/s |
| Maximum Write Transfer Rate | 510 MB/s |
| Random 4KB Read | 91000IOPS |
| Random 4KB Write | 38000IOPS |
| Network & Communication | |
| Wireless LAN | No |
| Technical Information | |
| Storage Capacity | 1.92 TB |
| Encryption Standard | 256-bit |
