Intellient Network Solutions 524179 1-port Power over Ethernet Injector - Black - Intellinet
(No reviews yet)
Write a Review
- SKU:
- 18056187
- MPN:
- 524179
- Availability:
- Out of stock
- Stock Update:
- 03/01/2022 02:17:51 PM PST
- Stock Update:
- 03/01/2022 02:17:51 PM PST
Description
This item is brand-new, factory sealed.
Ideal when ac power is not available full-power class 3 poe design power output of up to 15.4 watts supports all ieee 802.3af-compliant poe devices (wireless lan access points and bridges voip (voice over internet protocol) telephones ip surveillance cameras) supports ieee 802.3af detection and short circuit overload and high-voltage protectionFeatures
Package Contents:
- Power over Ethernet (PoE) Injector
- Power Cable
- Instruction Sheet
Certifications & Standards:
- IEEE 802.3af (Power over Ethernet)
- IEEE 802.3 (10Base-T Ethernet)
- IEEE 802.3u (100Base-TX Fast Ethernet)
Compatibility:
INTELLINET Wireless Access Points:
- 300N
- High Power Wireless G
INTELLINET Network Cameras:
- NBCC30-IR
- NFC30-IR
- NFC30
- NFD30
- NFC31
- NFC31-IR
Specs
| Power Description | |
| Maximum Frequency | 60 Hz |
| Minimum Frequency | 50 Hz |
| Maximum Output Voltage | 48 V DC |
| Maximum Output Current | 350 mA |
| Maximum Output Power | 15.40 W |
| Input Voltage |
|
| Physical Characteristics | |
| Weight (Approximate) | 4.94 oz |
| Length | 4.7" |
| Product Color | Black |
| Height | 1.4" |
| Color Family | Black |
| Width | 2" |
| Interfaces/Ports | |
| Output Ports | 1 x 10/100Base-T |
| Input Ports | 1 x 10/100Base-T |
| General Information | |
| Brand Name | Manhattan |
| Manufacturer Website Address | http://www.icintracom.com |
| Marketing Information | Reduce costs by using existing Cat5 cable to provide both power and data. The INTELLINET NETWORK SOLUTIONS Power over Ethernet Injector allows you to connect your IEEE 802.3af-compliant products to a non-PoE LAN switch port. The injector can be used to connect a wireless access point, IP phone, network camera or any IEEE 802.3af powered device (PD) to a switch. Reduce Wiring Costs No need to run AC power lines for your wireless access point, network camera or IP phone. Simply connect the PoE Injector to the LAN switch port, and use the existing Cat5 cabling to deliver DC power as well as transfer data. Preserve Existing Investments Does your existing LAN switch not support the new IEEE 802.3af PoE standard? Well, don't let that stop you from realizing the benefits of delivering DC power over the existing Cat5 Ethernet cabling. Use the Model 503389 PoE Injector until you are able to upgrade your LAN switch to a model that supports the IEEE 802.3af PoE standard. Protect Your Equipment Now that you are running DC power to your networked equipment through the Cat5 cabling, you need to be sure that the products are protected from power problems. The PoE Injector was designed to protect equipment from short circuits (short GRND), current overloads (over 450 mA) and high voltages (voltage exceeding 52 V). |
| Product Type | PoE Injector |
| Product Name | Power over Ethernet (PoE) Injector |
| Manufacturer | IC INTRACOM |
| Manufacturer Part Number | 524179 |
| Product Model | 524179 |
| Packaged Quantity | 1 |
