lian li
Lian li UNI FAN SLV2 120 Reverse Blade, Black color, single pack without controller -UF-RSL120V2-1B
- SKU:
- 20498594
- MPN:
- rsl120v2-1b
- Availability:
- Out of stock
- Stock Update:
- 05/02/2025 06:05:04 AM PST
- Stock Update:
- 05/02/2025 06:05:04 AM PST
Description
This item is brand-new, factory sealed.
- Slide In Daisy-Chain Style
- Improved Performance
- Sophisticate Lighting Effects
- Reversed Blade
- Start/ Stop Fan
- L-Connect 3 Software
CONSISTENT APPEARANCE
View the fan front way no matter intake or exhaust way.
UPGRADED MODULARITY
UNI FAN SL V2 reverse blade features an interlocking system to connect up to 6 fans in two clusters to a single controller port, making fans installation and cable management a simple job.
PLUG-IN POWER CABLE MODULE
Flush with fan frame, reduces clearance issues.
SLIDE-IN MECHANISM
Pin-to-pad contact, daisy-chaining the fan into a simple cluster.
REMOVABLE KEY
Remove the interlocking key to improve compatibility.
SINGLE CABLE TO CONTROLLER
(INCLUDED IN 3 PACK UNI FAN SL120-V2)
Combines fan power and LED signal into one cable, reduces cable clutter.
EXTENSION CABLE
(INCLUDED IN 3 PACK UNI FAN SL120-V2)
Bridges 2 fan clusters for a minimalistic cable solution.
UNCOMPROMISED PERFORMANCE
The UNI FAN SLV2 reverse blade operates with a slightly higher noise level with a better airflow compared to the original UNI FAN SLV2.
AIRFLOW
64.4 CFM
STATIC PRESSURE
2.19 mmH2O
NOISE
32 dBA
SPEED
0, 250-2000 RPM
REVERSED BLADE
Blade in the other way around
MAGNETIC FRAME
To provide extra support for fan blades
MAGNETIC RUBBER RING
To ensure extreme stability
FLUID DYNAMIC BEARING (FDB)
To effectively reduce the internal friction for improved durability
CIRCLIP
To secure the fan blades in place
STATOR
To provide a rotating magnetic field that generates momentum
EXTRA MAGNETIC FORCE
To support the fan blades and reduce vibration levels, thus ensuring a low noise level while in operation
RUBBER PADS
To reduce vibrations and ensure extremely low noise levels
SOPHISTICATED LIGHTING DESIGN | DETAIL ORIENTED
The cut edge of the rubber pads is designed to create a smoother curve along the light diffuser.
CONTINUOUS LED CHANNEL
The light gap between the two fans when interlocked together has been reduced from 5.6mm to 3mm, sketching out the elegant lighting effects.
L-CONNECT 3 SOFTWARE TO CONTROL UNI FAN SL V2 REVERSE BLADE FANS
Control and preview with precision the lighting effect of the UNI FAN SL V2 reverse blade fans with the new L-Connect interface.
Specs
| Power Description | |
| Rated Current | 170 mA |
| Physical Characteristics | |
| Product Material |
|
| Maximum Fan Diameter | 4.72" |
| Fan Width | 4.72" |
| Product Color | Black |
| Fan Depth | 1.10" |
| Color Family | Black |
| Fan Height | 4.72" |
| Warranty | |
| Limited Warranty | 2 Year |
| Interfaces/Ports | |
| Connectors |
|
| Fan Information | |
| Number of Fans | 1 |
| Fan Bearing Type | Fluid Dynamic Bearing |
| LED Color | ARGB |
| Maximum Airflow | 64.50 CFM |
| Maximum Air Pressure | 2.59mmH2O |
| Fan Speed (Max) | 2000 rpm |
| Noise Levels (A-Weighted) | 32 dB(A) |
| General Information | |
| Brand Name | Lian Li |
| Manufacturer Website Address | http://www.lian-li.com |
| Marketing Information | Slide In Daisy-Chain Style Improved Performance Sophisticate Lighting Effects Reversed Blade Start/ Stop Fan L-Connect 3 Software CONSISTENT APPEARANCE View the fan front way no matter intake or exhaust way. UPGRADED MODULARITY UNI FAN SL V2 reverse blade features an interlocking system to connect up to 6 fans in two clusters to a single controller port, making fans installation and cable management a simple job. PLUG-IN POWER CABLE MODULE Flush with fan frame, reduces clearance issues. SLIDE-IN MECHANISM Pin-to-pad contact, daisy-chaining the fan into a simple cluster. REMOVABLE KEY Remove the interlocking key to improve compatibility. SINGLE CABLE TO CONTROLLER (INCLUDED IN 3 PACK UNI FAN SL120-V2) Combines fan power and LED signal into one cable, reduces cable clutter. EXTENSION CABLE (INCLUDED IN 3 PACK UNI FAN SL120-V2) Bridges 2 fan clusters for a minimalistic cable solution. UNCOMPROMISED PERFORMANCE The UNI FAN SLV2 reverse blade operates with a slightly higher noise level with a better airflow compared to the original UNI FAN SLV2. AIRFLOW 64.4 CFM STATIC PRESSURE 2.19 mmH2O NOISE 32 dBA SPEED 0, 250-2000 RPM REVERSED BLADE Blade in the other way around MAGNETIC FRAME To provide extra support for fan blades MAGNETIC RUBBER RING To ensure extreme stability FLUID DYNAMIC BEARING (FDB) To effectively reduce the internal friction for improved durability CIRCLIP To secure the fan blades in place STATOR To provide a rotating magnetic field that generates momentum EXTRA MAGNETIC FORCE To support the fan blades and reduce vibration levels, thus ensuring a low noise level while in operation RUBBER PADS To reduce vibrations and ensure extremely low noise levels SOPHISTICATED LIGHTING DESIGN | DETAIL ORIENTED The cut edge of the rubber pads is designed to create a smoother curve along the light diffuser. CONTINUOUS LED CHANNEL The light gap between the two fans when interlocked together has been reduced from 5.6mm to 3mm, sketching out the elegant lighting effects. L-CONNECT 3 SOFTWARE TO CONTROL UNI FAN SL V2 REVERSE BLADE FANS Control and preview with precision the lighting effect of the UNI FAN SL V2 reverse blade fans with the new L-Connect interface. |
| Product Type | Cooling Fan |
| Product Name | UNI FAN SL120 V2 REVERSE BLADE |
| Manufacturer | Lian Li Industrial Co., Ltd |
| Manufacturer Part Number | RSL120V2-1B |
| Product Model | UF-RSL120V2-1B BLACK |
| Product Line | UNI FAN SL120 V2 REVERSE BLADE |
| Packaged Quantity | 1 |
Warranty Information
