MSI MAGA750BNPCIE5III MAG 750W Bronze Power Supply
- SKU:
- 21374963
- MPN:
- maga750bnpcie5iii
- Availability:
- Usually ships the same or next business day. In stock at our CA warehouse.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 10/23/2026 05:15:06 AM PST
Bulk discount rates
Below are the available bulk discount rates for each individual item when you purchase a certain amount
| Buy 2 | and pay only $91.22 each 91.22 |
| Buy 3 or above | and pay only $89.41 each 89.41 |
- Stock Update:
- 10/23/2026 05:15:06 AM PST
Description
This item is brand-new, factory sealed.
MSI's mainstream MAG series epitomizes stability and durability and is built to withstand the most intense gaming sessions. The entire lineup features robust construction with metallic-like hardness and excellent heat dissipation, ensuring stability for all critical gaming components.
80 PLUS BRONZE CERTIFIED
The efficiency of your power supply directly influences your system's performance and your power consumption. The 80 PLUS BRONZE certification promises lower energy consumption and higher efficiency.
ATX 3.1 READY
It has an output port that is compliant with PCIe CEM 5.1 and Intel PSDG (Power Supply Design Guide)ATX 3.1, also this power supply can hold up to 2x total power excursion and 3x GPU power excursion.
Embossed Jacket Modular Cable
Using premium materials to enhance the cable's flexibility and bendability, the sleek matt black design not only elevates its appearance but also makes cable management significantly easier and more sophisticated for users.
Dual-color 12V-2x6 cable
The 12V-2x6 cable's connector color has been changed to yellow so that users can easily see if the connector has been plugged in properly.
Offer the CPU sufficient power
This power supply features dual 4+4-pin PCIe power connectors, providing ample 12V power to support high-performance CPUs.
- 8+8 power connector
- 8+4 power connector
POWER AT YOUR SIDE
The power supply is built with DC-to-DC construction, ensuring top-tier efficiency and unwavering voltage stability for your system.
SET FREE FOR THE +12V POWER OUTPUT
The latest CPUs and graphics cards demand more power, and a single +12V rail PSU provides an ideal combination of simplicity, robust power delivery.
Alloy Copper Connector Terminals
The cable connectors are made of copper alloy terminals so that thepower supply will be safer when there is a higher surge in current.
Built for Maximum Safety
The power supply's cables, from the internal copper wires to the external high-density braided cover, are fully UL certified, ensuring superior safety and durability.
PROTECTION MECHANISMS
operate safely and stably at all times, this power supply comes with a number of protection mechanisms to give you the best peace of mind.
- OVP Over Voltage Protection
- OCP Over Current Protection
- SCP Short Circuit Protection
- OPP Over Power Protection
- UVP Under Voltage Protection
Connectors
This non-modular power supply is equipped with soft cables, making cable management easier.
Features
80 Plus Bronze
Specs
| Power Description | |
| Input Frequency | 50-60Hz |
| Number of +12V Rails | 1 |
| Output Power | 750 W |
| Output Current |
|
| Input Voltage Range | 100 V AC - 240 V AC |
| Input Voltage |
|
| Output Voltage Detail |
|
| Output Voltage |
|
| Physical Characteristics | |
| Form Factor | Internal |
| Height | 3.4" |
| Width | 5.9" |
| Depth | 5.5" |
| Warranty | |
| Limited Warranty | 5 Year |
| Interfaces/Ports | |
| Number of (6+2 pin) PCI Express Power Connectors | 3 |
| Number of 4-pin Molex Power Connectors | 2 |
| PCI Express Version | 5.1 |
| Number of (4+4 pin) CPU Power Connectors | 2 |
| Number of SATA Power Connectors | 3 |
| PCI Express Connector | Yes |
| General Information | |
| Brand Name | MSI |
| Manufacturer Website Address | http://www.msi.com |
| Marketing Information | MSI's mainstream MAG series epitomizes stability and durability and is built to withstand the most intense gaming sessions. The entire lineup features robust construction with metallic-like hardness and excellent heat dissipation, ensuring stability for all critical gaming components. 80 PLUS BRONZE CERTIFIED The efficiency of your power supply directly influences your system's performance and your power consumption. The 80 PLUS BRONZE certification promises lower energy consumption and higher efficiency. ATX 3.1 READY It has an output port that is compliant with PCIe CEM 5.1 and Intel PSDG (Power Supply Design Guide)ATX 3.1, also this power supply can hold up to 2x total power excursion and 3x GPU power excursion. Embossed Jacket Modular Cable Using premium materials to enhance the cable's flexibility and bendability, the sleek matt black design not only elevates its appearance but also makes cable management significantly easier and more sophisticated for users. Dual-color 12V-2x6 cable The 12V-2x6 cable's connector color has been changed to yellow so that users can easily see if the connector has been plugged in properly. Offer the CPU sufficient power This power supply features dual 4+4-pin PCIe power connectors, providing ample 12V power to support high-performance CPUs. 8+8 power connector 8+4 power connector POWER AT YOUR SIDE The power supply is built with DC-to-DC construction, ensuring top-tier efficiency and unwavering voltage stability for your system. SET FREE FOR THE +12V POWER OUTPUT The latest CPUs and graphics cards demand more power, and a single +12V rail PSU provides an ideal combination of simplicity, robust power delivery. Alloy Copper Connector Terminals The cable connectors are made of copper alloy terminals so that thepower supply will be safer when there is a higher surge in current. Built for Maximum Safety The power supply's cables, from the internal copper wires to the external high-density braided cover, are fully UL certified, ensuring superior safety and durability. PROTECTION MECHANISMS operate safely and stably at all times, this power supply comes with a number of protection mechanisms to give you the best peace of mind. OVP Over Voltage Protection OCP Over Current Protection SCP Short Circuit Protection OPP Over Power Protection UVP Under Voltage Protection Connectors This non-modular power supply is equipped with soft cables, making cable management easier. |
| Product Type | Power Supply |
| Product Name | MAG 750W Power Supply |
| Manufacturer | MSI |
| Manufacturer Part Number | MAGA750BNPCIE5III |
| Product Series | MAG |
| Technical Information | |
| Fan Diameter | 120 mm |
| Specification Compliance | ATX 3.1 |
| Efficiency | 85% |
| Number of Fans | 1 |
| Fan Bearing Type | Hydraulic Bearing |
| Protection Type |
|
| Features |
|
| Modular | No |
| Power Factor Correction (PFC) | Active |
