Qnap
QNAP QSWM7308R4XUS 12-Port 100GbE Layer 2 Managed Switch Half-Width Rackmount
- SKU:
- 21250749
- MPN:
- qsw-m7308r-4x-us
- Availability:
- Usually ships the same or next business day. In stock at our IL warehouse.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 11/05/2026 12:55:15 AM PST
- Stock Update:
- 11/05/2026 12:55:15 AM PST
Description
This item is brand-new, factory sealed.
The QSW-M7308R-4X is a 100GbE L2 Managed Switch with four 100GbE QSFP28 and eight 25GbE SFP28 ports. The QSW-M7308R-4X can uplink to 100G/25G servers and NAS in server rooms or connect to 100G/25G switches to accelerate high-speed storage, video editing, virtualization, and AI applications. With competitive pricing and space-saving features, the QSW-M7308R-4X enables businesses to quickly upgrade to an ultra-high-speed backbone network infrastructure for building ultra-high-speed network transmission and storage solutions. The QSW-M7308R-4X is made in Taiwan (MIT), providing a high-quality and reliable networking solution.
100GbE/25GbE Network
Includes four 100GbE QSFP28 and eight 25GbE SFP28 fiber ports to offer a backbone switching capacity of 1200Gbps for uplinking server rooms.
User-friendly management interface
The user-friendly QNAP Switch System (QSS) centralizes and simplifies central network management with an overview dashboard, port management, and settings guide.
Layer 2 network
Provides Layer 2 management features (such as LACP, VLAN, ACL and LLDP) for efficiently controlling network bandwidth and enhancing security.
Space-saving half-width design
One of the few compact 100GbE switches on market, the QSW-M7308R-4X, can be installed in a 1U rack space with another half-width rackmount switch for efficient physical space utilization.
Compatible with QNAP NAS
Supports FEC (Forward Error Correction) and IEEE-802.3ap Auto-Negotiation for high compatibility to connect to QNAP 25GbE NAS or NAS installing 100G network cards for high-performance, low-latency computing.
Online firmware update
QSS can be updated with just one click, helping IT staff ensure their network security.
Embrace the ultra-high-speed 100GbE network generation!
According to market research, the demand for 100GbE switches has taken off in 2023. Enterprises, hyperscalers, and service providers worldwide continue to invest in higher-speed network infrastructure to support higher-speed servers and higher bandwidth demands of new applications such as Generative AI workloads.
With the prevailing 10GbE and 25GbE networks, explosive growth of big data transmission and high-density workloads is driving demands for ultra-high-speed 100GbE networks. The QSW-M7308R-4X 100GbE switch assists enterprises in deploying 100GbE networks in the existing network infrastructure with cost-effectiveness, resolving performance bottlenecks.
- Media professionals4K/8K video transmission
- Storage CentersBig Data applications
- Medium to large enterprisesCloud & AI computing
- Smart medicineDNA sequence computing
The best 100GbE network switch for SMBs | Cost-optimal
The QSW-M7308R-4X offers 1200Gbps switching capacity at a budget-friendly price. Businesses can flexibly deploy medium-to-large scale high-speed network infrastructure using the QSW-M7308R-4X coupled with QNAP 25GbE/10GbE switches.
Compact
Two half-width rackmount QSW-M7308R-4X can be installed in a 1U rack space, or with another half-width rackmount switch.
Best for QNAP NAS
Ultra-high-speed 100GbE switches can connect to QNAP 25GbE NAS or NAS installing 100G network cards fulfilling high bandwidth demands for high-density I/O data transmission.
Package Contents:
- QSW-M7308R-4X Ethernet Switch
- Power Cord
- Rackmount kit
- Foot pads
- Screw
- Quick Installation Guide (QIG)
Features
- QSW-M7308R-4X Ethernet Switch
- Power Cord
- Rackmount kit
- Foot pads
- Screw
- Quick Installation Guide (QIG)
Application/Usage:
Network
Business
Enterprise
Industrial
NAS
Server
Infrastructure
Building
Security
Data Storage
Traffic
Country of Origin:
Taiwan
Specs
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| Power Source |
|
| Frequency |
|
| Input Voltage |
|
| Power Consumption | 100 W |
| Physical Characteristics | |
| Form Factor |
|
| Weight (Approximate) | 3.92 lb |
| Height | 1.7" |
| Compatible Rack Unit | 1U |
| Width | 8.1" |
| Depth | 9.8" |
| Warranty | |
| Limited Warranty | 2 Year |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Port/Expansion Slot Details |
|
| I/O Expansions | |
| Total Number of Expansion Slots | 12 |
| Expansion Slot Type |
|
| General Information | |
| Brand Name | QNAP |
| Manufacturer Website Address | http://www.qnap.com |
| Marketing Information | The QSW-M7308R-4X is a 100GbE L2 Managed Switch with four 100GbE QSFP28 and eight 25GbE SFP28 ports. The QSW-M7308R-4X can uplink to 100G/25G servers and NAS in server rooms or connect to 100G/25G switches to accelerate high-speed storage, video editing, virtualization, and AI applications. With competitive pricing and space-saving features, the QSW-M7308R-4X enables businesses to quickly upgrade to an ultra-high-speed backbone network infrastructure for building ultra-high-speed network transmission and storage solutions. The QSW-M7308R-4X is made in Taiwan (MIT), providing a high-quality and reliable networking solution. 100GbE/25GbE Network Includes four 100GbE QSFP28 and eight 25GbE SFP28 fiber ports to offer a backbone switching capacity of 1200Gbps for uplinking server rooms. User-friendly management interface The user-friendly QNAP Switch System (QSS) centralizes and simplifies central network management with an overview dashboard, port management, and settings guide. Layer 2 network Provides Layer 2 management features (such as LACP, VLAN, ACL and LLDP) for efficiently controlling network bandwidth and enhancing security. Space-saving half-width design One of the few compact 100GbE switches on market, the QSW-M7308R-4X, can be installed in a 1U rack space with another half-width rackmount switch for efficient physical space utilization. Compatible with QNAP NAS Supports FEC (Forward Error Correction) and IEEE-802.3ap Auto-Negotiation for high compatibility to connect to QNAP 25GbE NAS or NAS installing 100G network cards for high-performance, low-latency computing. Online firmware update QSS can be updated with just one click, helping IT staff ensure their network security. Embrace the ultra-high-speed 100GbE network generation! According to market research, the demand for 100GbE switches has taken off in 2023. Enterprises, hyperscalers, and service providers worldwide continue to invest in higher-speed network infrastructure to support higher-speed servers and higher bandwidth demands of new applications such as Generative AI workloads. With the prevailing 10GbE and 25GbE networks, explosive growth of big data transmission and high-density workloads is driving demands for ultra-high-speed 100GbE networks. The QSW-M7308R-4X 100GbE switch assists enterprises in deploying 100GbE networks in the existing network infrastructure with cost-effectiveness, resolving performance bottlenecks. Media professionals4K/8K video transmission Storage CentersBig Data applications Medium to large enterprisesCloud & AI computing Smart medicineDNA sequence computing The best 100GbE network switch for SMBs | Cost-optimal The QSW-M7308R-4X offers 1200Gbps switching capacity at a budget-friendly price. Businesses can flexibly deploy medium-to-large scale high-speed network infrastructure using the QSW-M7308R-4X coupled with QNAP 25GbE/10GbE switches. Compact Two half-width rackmount QSW-M7308R-4X can be installed in a 1U rack space, or with another half-width rackmount switch. Best for QNAP NAS Ultra-high-speed 100GbE switches can connect to QNAP 25GbE NAS or NAS installing 100G network cards fulfilling high bandwidth demands for high-density I/O data transmission. |
| Product Type | Ethernet Switch |
| Product Name | QSW-M7308R-4X Ethernet Switch |
| Manufacturer | QNAP Systems |
| Manufacturer Part Number | QSW-M7308R-4X-US |
| Product Model | QSW-M7308R-4X |
| Media & Performance | |
| Ethernet Technology |
|
| Media Type Supported | Optical Fiber |
| Network Technology |
|
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards |
|
