Rocstor
Rocstor Y10G001B1 HDMI Extender Over CAT6/CAT6A/CAT7
(No reviews yet)
Write a Review
- SKU:
- 20536796
- MPN:
- y10g001-b1
- Availability:
- Out of stock
- Stock Update:
- 09/28/2026 09:39:15 AM PST
- Stock Update:
- 09/28/2026 09:39:15 AM PST
Frequently bought together:
Description
This item is brand-new, factory sealed.
4K@60Hz HDMI Extender over CAT6/CAT6a/Cat7 Ethernet Cable up to 230ft Point to Point ExtenderFeatures:
Zero latency HDMI extender for seamless audiovisual transmission
Supports 4K @ 60Hz HDR resolution for breathtaking visuals
Transmission distance of up to 131 ft (40 meters) for 4K @ 60Hz and 70 meters for 1080p @ 60Hz signals
IP color image capability for versatile applications, including security systems
Built-in , surge, and ESD protection for equipment safety
IR pass-through feature for convenient control of HDMI source devices from the remote display location
EDID passthrough ensures smooth communication between source and display
Compatible with Cat6, Cat6A, and Cat7 network cables
Adaptive technology automatically adjusts parameters for optimal display performance
Ideal for professional presentations, multimedia centers, digital signage systems, and more.Specification
Transmitter
Video Signal
Input
1xHDMI Type A, Female
Output
1xHDMI Type A, Female
HDMI Cable
3-5m
Max Transmission Rate
18Gbps
Max Transmission Bandwidth
600MHz
EDID Pass back
Support
Compatibility
HMDI2.0 (Deep color/4K/HDR/YUV4:4:4)
HDCP2.2
Resolution
4096x2160 at 24/25Hz, 3840x2160 at 24/25/30/50/60Hz, 1080i at 50/60Hz, 1080p at 50/60Hz, 720p at 50/60Hz, 480i at 60Hz, 480p at 60Hz, 576i at 50Hz, 576p at 50Hz
1280x960, 1280x800, 1280x768, 1680x1050, 1360x768, 1366x768, 1600x900, 1024x768, 800x600
Network
1xRJ-45, Female
Distance
CAT6/6A/7 < or equals 70m
Audio Signal
Input
1xHDMI Type A, Female
Output
1xHDMI Type A, Female
Formats
LPCM/DTS-HD/DTS-Audio/Dolby Digital 5.1CH/Dolby Atmos
Control Signal
IR Interface
1x3.5mm IR OUT, Female
Range
< 5m
Frequency
20-60KHz
Power Supply
Interface
1xDC5V_2.1 jack, without thread
Voltage
DC5V/1A
Working Power
<3W
Operating Environment
Operating Temperature
-20 to 60oC
Storage Temperature
-30 to 70oC
Humidity
0 to 90%(No Condensation)
Physical Properties
Material
Iron
Colour
BlackStatic Protection
ESD Protection
1a Contact discharge 2 Level (+/-4KV)
1b Air discharge 3 Level (+/- 8KV)
StandardIEC61000-4-2
Lighting protection, Surge protection
Certification
FCC/CE/RoHS
Rack-mounted
SupportItem Dimension (L inchxW inchxH inch)
6 x 8 x 4
Weight
2 lbs
Warranty Information
2-year Limited
Features
Package Contents:
Yes
China
- 1 x Local HDMI Transmitter Unit
- 1 x Remote HDMI Receiver Unit
- 1 x Power Adapter
- 1 x Quick-Start Guide
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Waste Electrical and Electronic Equipment Directive (WEEE)
Country of Origin:
China
Specs
| Physical Characteristics | |
| Form Factor | Wall Mountable |
| Transmitter Weight (Approximate) | 5.28 oz |
| Receiver Width | 3.35" |
| Receiver Height | 0.63" |
| Product Color | Black |
| Receiver Depth | 1.69" |
| Transmitter Depth | 1.69" |
| Receiver Weight (Approximate) | 5.28 oz |
| Color Family | Black |
| Transmitter Height | 0.63" |
| Transmitter Width | 3.35" |
| Warranty | |
| Limited Warranty | 2 Year |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| HDMI Out | Yes |
| Number of HDMI Inputs | 1 |
| HDMI In | Yes |
| Number of HDMI Outputs | 2 |
| Number of Network (RJ-45) Ports | 2 |
| Video | |
| Maximum Video Resolution | 4096 x 2160 |
| Supported Video Modes |
|
| Graphics Modes | 4K |
| General Information | |
| Brand Name | Rocstor |
| Manufacturer Website Address | http://www.rocstor.com |
| Marketing Information | Elevate your audiovisual experience to new heights with the Rocstor TrueReach Point to Point 4K @ 60Hz HDMI Extender. Engineered for exceptional performance and reliability, this advanced extender enables you to extend high-quality HDMI signals over long distances. With zero latency and a transmission distance of up to 70 meters, the TrueReach HDMI Extender ensures seamless, high-definition content delivery. Experience breathtaking visuals with support for 4K resolution at 60Hz with HDR. Whether you're setting up a professional presentation space, a multimedia center, or a digital signage system, the TrueReach HDMI Extender guarantees vibrant colors, sharp details, and a truly immersive viewing experience. The TrueReach extender goes beyond video transmission, offering IP color image capability. This feature allows for a broader range of applications, such as security systems and remote monitoring, where both video and color information are crucial for accurate representation. With built-in lightning, surge, and ESD (electrostatic discharge) protection, the Rocstor TrueReach HDMI Extender ensures your valuable equipment remains safe and secure, even in unpredictable electrical environments. This protection safeguards your investment and provides peace of mind. The TrueReach HDMI Extender features convenient IR pass-through, allowing you to control your HDMI source devices from the remote display location. No more hassle of moving between devices or searching for separate control systems. Enjoy seamless control and enhanced usability. Thanks to its compatibility with Cat6, Cat6A, and Cat7 network cables, the Rocstor TrueReach adapts effortlessly to different cable types. Its adaptive technology automatically adjusts parameters to optimize display performance, ensuring a stable and reliable connection. Experience the freedom to extend your HDMI signals without compromising on video quality or signal integrity. |
| Product Type | Video Extender Transmitter/Receiver |
| Product Name | TrueReach HDMI Extender |
| Manufacturer | Rocstor |
| Manufacturer Part Number | Y10G001-B1 |
| Product Model | Y10G001-B1 |
| Product Line | TrueReach |
| Packaged Quantity | 1 Box |
| Media & Performance | |
| Twisted Pair Cable Standard | Category 7 |
| Media Type Supported | Twisted Pair |
| Technical Information | |
| Maximum Operating Distance | 229.66 ft |
| Number of Input Devices Supported | 1 |
| Connectivity Technology | Wired |
| Number of Output Devices Supported | 1 |
Warranty Information
All Items are Brand New, Factory Sealed and come with a standard warranty. [Read our policies]
