Shuttle XPC slim DH610 Barebone System - Slim PC - Socket LGA-1700 - 1 x Processor Support
(No reviews yet)
Write a Review
- SKU:
- 19910052
- MPN:
- dh610
- Availability:
- Usually ships the same or next business day. In stock at our PA warehouse.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 06/04/2026 06:30:10 PM PST
Bulk discount rates
Below are the available bulk discount rates for each individual item when you purchase a certain amount
| Buy 2 or above | and pay only $507.11 each 507.11 |
- Stock Update:
- 06/04/2026 06:30:10 PM PST
Frequently bought together:
Description
This item is brand-new, factory sealed.
13th/12th Gen Hybrid Power Makes Multitask EasyShuttle XPC Slim series DH610 supports Intel 13th/12th Gen LGA1700 processors. With Intel new performance hybrid architecture and UHD graphics 700 series integrated, the model computes performance along with the potential for powering AI deployment. Support up to three displays via one HDMI 2.0b and two DisplayPort for display productivity and flexibility. Moreover, the model provides comprehensive connectivity with multiple ports, including four USB 3.2 Gen1 (Including one Type-C), four USB 2.0, two RS232, Intel 2.5GbE + Intel 1GbE LAN, and two M.2 expansion slots. DH610 can perform a reliable operation suitable for Office, Digital Signage, Kiosks, and other Multi-platform AI deployment.
Intel 13th Gen processor
Based on the H610 chipset, DH610 is designed for 13th/12th Gen Intel processors in the LGA1700 socket and supports up to 64GB (32GBx2) of DDR4-3200 memory, which delivers a performance improvement uplift of up to 28%, providing powerful computing capacity. In addition, with Intel UHD Graphics 700 series integrated, DH610 is potential for multi-platform AI deployment.
Triple-Display Productivity
With one HDMI 2.0b and two DisplayPort outputs built-in, DH610 supports three independent displays, providing productivity benefits and dynamic visualization for multitasking and digital signage applications.
Strong Expansion Capacity with M.2
With a native M.2 2280/2260/2242 Type M slot and an M.2 2230 Type E slot, DH610 offers considerably faster storage performance and expansion capacity for M.2 SSD and Wi-Fi modules.
*M.2 2280 key M supports SATA 3.0 and PCIe 3.0 x 4 storage interfaces.FORM FACTOR
1.3L chassisPROCESSOR
Support Intel 12/13th LGA1700 socket Core i3/i5/i7/i9, Pentium, Celeron 65W processor
Note BIOS v2.02 and updated version support Raptor Lake (13th) CPUCHIPSET
Intel H610 Express chipsetMEMORY
2 x DDR4 SODIMM slots,32GB per DIMM (Max 64GB)
DDR4 up to 3200 MHzVIDEO OUTPUT
HDMI 2.0 x 1+ DisplayPort x 2, Triple video outputs
4K playback (Dual channel memory recommended)
Integrated in CPUAUDIO
Realtek High Definition AudioETHERNET
(1) Intel GbE Lan / (1)2.5 GbE Lan
10Mb/s,100Mb/s,1Gb/s operation
Support Wake-On-LAN function
Support Teaming functionSTORAGE INTERFACE
SATA 6.0Gb/s interfaceONBOARD CONNECTORS
(1) 4pin fan connector
(1) VGA(For PVG01 use)
(1) 1x4 pin USB header(For WWN03 use)
(1) SATA connector w/power
(1) Front audio header
(1) Auto power on header
(1) RS232 voltage switchFRONT PANEL
(2) USB 3.2 Gen1 ports
(Include Type C x1)
(2) USB 2.0 ports
(1) Microphone-In
(1) Line-Out
(1) Power-On button
(1) Power LED
(1) HDD LEDBACK PANEL
(2) RJ45 Gigabit LAN port w/LED
(1) HDMI port
(2) Display port
(2) USB 3.2 Gen1 ports
(2) USB 2.0 ports
(1) RS232
(1) RS232/RS422/RS485
(1) External 4pin header
(1) DC-in
(2) Wireless Antenna fixture
(1) Kensington lockDRIVE BAYS
(1) 2.5" HDD / SSD bayPOWER
120W Power Adapter
Input:100-240V AC
19V 6.32A
Note DH610 support 12V DC input.ACCESSORIES
XPC Multilanguage Quick User Guide
XPC DVD Driver
VESA mount
VESA Screw pack
Power cord
Thermal Grease
HDD Screw pack
120W adapterEXPANSION SLOT
(1) M.2 2280 Type M key socket
(1) M.2 2230 Type E key socketOS SUPPORT
Windows 10/11 64-bit O.S
LinuxREMARK
RS232/422/485 ports support 0/5/12V output. Voltage setting please refer to Quick Guide.OPERATING TEMPERATURE
0oC-50oCItem Dimension (L inchxW inchxH inch)
11 x 6 x 10
Weight
5 lbs
Warranty Information
3 Years
Features
Package Contents:
Yes
Energy-related Products Directive (ErP)
Yes
Restriction of Hazardous Substances (RoHS)
- XPC slim DH610 Barebone System
- Multi-Language User Guide (EN, DE, FR, ES, JP, KR, SC, TC)
- VESA Mount For 75/100 mm Standard (two metal brackets)
- 4 x Screws M3 x 5 mm (screws together VESA mount and PC)
- 4 x Screws M4 x 10 mm (to affix VESA mount on the PC)
- 4 x Screws M3 x 4 mm (to mount a 2.5" storage device into the bay)
- 2 x Screws M3 x 5 mm (silver colour, to mount two M.2 cards)
- Driver DVD (Windows 64-bit)
- Serial ATA Cable For 2.5" Drive Including Power Cable
- External 120 W Power Adapter With Power Cord
- Protection Cap For CPU Socket (do not use if heatpipe or fan is mounted)
- Heatsink Compound
Environmentally Friendly:
Yes
Energy Efficiency Compliance:
Energy-related Products Directive (ErP)
Energy Star:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Specs
| Controllers | |
| Controller Type | Serial ATA/600 |
| Power Description | |
| Maximum Power Supply Wattage | 120 W |
| Frequency |
|
| Input Voltage |
|
| Processor | |
| Processor Supported |
|
| Processor Socket | Socket LGA-1700 |
| Number of Processors Supported | 1 |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | H610 |
| Physical Characteristics | |
| Form Factor | Slim PC |
| Weight (Approximate) | 2.87 lb |
| Product Color | Black |
| Height | 1.7" |
| Color Family | Black |
| Width | 6.5" |
| Depth | 7.5" |
| I/O Expansions | |
| Number of Total Expansion Bays | 1 |
| Memory | |
| Memory Technology | DDR4 SDRAM |
| Maximum Memory Supported | 64 GB |
| Total Number of Memory Slots | 2 |
| Memory Standard | DDR4-3200/PC4-25600 |
| Display & Graphics | |
| Graphics Memory Accessibility | Shared |
| Graphics Memory Technology | DDR4 SDRAM |
| General Information | |
| Brand Name | Shuttle |
| Manufacturer Website Address | http://www.us.shuttle.com |
| Marketing Information | Robust 1.3-litre Slim PC supports Intel Core Gen. 12 processors "Alder Lake-S" and two UHD displays The Shuttle XPC slim Barebone DH610 with H610 chipset houses the performance of Intel's 12th generation Core desktop processors (codenamed Alder Lake-S) for socket LGA1700 in a compact 1.3-litre format. The DH610 allows for three Ultra HD displays to be operated at the same time via 1x HDMI and 2x DisplayPort. It also offers Dual Intel LAN (one supports 2.5G speed), eight USB ports and two COM ports. The slim metal chassis comes with a VESA mount included, provides versatile connectivity and reliable operation in environments with ambient temperatures of up to 50 °C. This platform is targeted at professional applications such as Digital Signage, POS, POI, gambling machines, office, healthcare and industry. |
| Product Type | Barebone System |
| Product Name | XPC slim DH610 Barebone System |
| Manufacturer | Shuttle, Inc |
| Manufacturer Part Number | DH610 |
| Product Model | DH610 |
| Product Line | XPC slim |
| Interfaces/Ports | |
| USB Type-C Detail | 1 x USB 3.2 Gen 1 Type-C |
| USB Type-C (Front) | Yes |
| Total Number of USB Ports | 8 |
| Number of USB 3.2 Gen 1 Ports | 3 |
| HDMI (Rear) | Yes |
| Network & Communication | |
| Ethernet Technology |
|
| Operating System | |
| Operating System Supported |
|
