StarTech.com 2.5in SATA/SAS SSD/HDD to 3.5in SATA Hard Drive Converter - Storage Bay Adapter - Black 25SATSAS35
- SKU:
- 18055789
- MPN:
- 25satsas35
- Availability:
- Usually ships the same or next business day. In stock at our MS warehouse.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 04/22/2024 04:21:26 PM PST
Bulk discount rates
Below are the available bulk discount rates for each individual item when you purchase a certain amount
Buy 2 or above | and pay only $23.70 each 23.7 |
- Stock Update:
- 04/22/2024 04:21:26 PM PST
Description
This item is brand-new, factory sealed.
The 25SATSAS35 2.5-inch SATA/SAS to 3.5-inch SATA Hard Drive Converter converts a 2.5-inch SATA or SAS hard drive (HDD) or solid state drive (SSD) into a 3.5-inch form factor SATA Hard Drive.The converter provides a versatile solution for 2.5-inch drive installations, enabling you to install a 2.5-inch SATA/SAS drive in a 3.5-inch bay, drive drawer caddy/tray, or into a 3.5-inch drive enclosure.
Suitable for drives with a height of up to 15mm, virtually any 2.5-inch SATA or SAS hard drive can be made to look and function like a 3.5-inch hard drive - complete with standard mounting points along the sides and bottom (including 3 points along the sides for compatibility with some Dell systems).
The Drive Converter features a trayless design for simple drive installation and removal, and is constructed of durable, yet lightweight plastics, with ventilation openings to aid air flow and help keep hard drives running cooler. Color:
Black
Drive Connectors:
1 - SFF-8482 (29 pin Data Power Internal SAS) Receptacle
Drive Installation:
Removable Drive Size:
2.5in
Drive Type:
SAS and SATA
Enclosure Type:
Plastic
Fan(s) :
No Host Connectors:
1 - SATA Data and Power Combo (7+15 pin) Plug
Key Lock:
No
Max Drive Height:
0.59 in (15 mm) Number of 2.5 inch bays:
1
Number of Drives:
1
RAID:
No
Temperature Alarm:
NoItem Dimension (L"xW"xH"):
6.42 x 4.13 x 1.14
Weight:
0.39 lb
Warranty Information
2 Years
Features
Package Contents:
Yes
China
- 2.5in SATA/SAS SSD/HDD to 3.5in SATA Hard Drive Converter
- 10 x Screws (6 Round, 4 Flat)
Certifications & Standards:
- FCC
- CE
Environmental Certification:
RoHS
REACH
WEEE
Additional Information:
- A trayless design and support for 15mm drives enables quick and easy install/removal of drives, including newer high capacity drives
- Uses standard 3.5" form factor mounting points, along with 3 mounting points on the sides, for compatibility with some OEM branded systems, such as Dell
- Can be mounted into a 3.5" front bay as a 2.5" HDD Mobile Rack or treated as a regular 3.5" hard drive
Environmentally Friendly:
Yes
Country of Origin:
China
Specs
Physical Characteristics | |
Product Material | Plastic |
Cooling Fan | No |
Form Factor | Internal |
Weight (Approximate) | 4.80 oz |
Product Color | Black |
Height | 1" |
Compatible Drive Bay Width | 3.5" |
Width | 3.9" |
Depth | 5.7" |
Warranty | |
Limited Warranty | 2 Year |
I/O Expansions | |
Number of 2.5" Bays | 1 |
Number of Total Expansion Bays | 1 |
Interfaces/Ports | |
Host Interface | Serial ATA/600 |
Drive Interface |
|
General Information | |
Brand Name | StarTech.com |
Manufacturer Website Address | http://www.startech.com |
Marketing Information | The 25SATSAS35 2.5-inch SATA/SAS to 3.5-inch SATA Hard Drive Converter converts a 2.5-inch SATA or SAS hard drive (HDD) or solid state drive (SSD) into a 3.5-inch form factor SATA Hard Drive. The converter provides a versatile solution for 2.5-inch drive installations, enabling you to install a 2.5-inch SATA/SAS drive in a 3.5-inch bay, drive drawer caddy/tray, or into a 3.5-inch drive enclosure. To maximize performance and utilize the full speed potential of your SATA III hard drives, this HDD Backplane supports SATA III for transfer speeds up to 6 Gbps when paired with compatible controller. Suitable for drives with a height of up to 15mm, virtually any 2.5-inch SATA or SAS hard drive can be made to look and function like a 3.5-inch hard drive. The drive converter includes mounting holes along the side and base, allowing you to mount the drive if needed, into a compatible system. The Drive Converter features a trayless design for simple drive installation and removal, and is constructed of durable, yet lightweight plastics, with ventilation openings to aid air flow and help keep hard drives running cooler. Backed by a StarTech.com 2-year warranty and free lifetime technical support. More from the Manufacturer |
Product Type | Drive Bay Adapter |
Product Name | 2.5in SATA/SAS SSD/HDD to 3.5in SATA Hard Drive Converter |
Manufacturer | StarTech.com |
Manufacturer Part Number | 25SATSAS35 |
Packaged Quantity | 1 |
Network & Communication | |
Wireless LAN | No |
Technical Information | |
Number of Hard Drives Supported | 1 |
Number of Hard Drives Installed | No |
Number of Solid State Drive Installed | No |
Number of Solid State Drive Supported | 1 |
