Startech.com 221135 Startech Ac Dkt30csdhpd3 Usb-c Multiport Adapter W Hdmi 2xa 1xc Pd 3.0 Retail

SKU:
18058371
MPN:
221135
Availability:
Usually ships the same or next business day. In stock at our GA, PA warehouses.
Shipping:
Calculated at Checkout
Stock Update:
08/12/2022 04:13:14 AM PST
  • Main
  • Alternate-Image4
  • Alternate-Image3
  • Alternate-Image2
  • Alternate-Image1
$81.17

Bulk discount rates

Below are the available bulk discount rates for each individual item when you purchase a certain amount

Buy 4 - 9 and pay only $79.76 each 79.76
Buy 10 or above and pay only $77.86 each 77.86
Stock Update:
08/12/2022 04:13:14 AM PST
Frequently bought together:

Description

This item is brand-new, factory sealed.

This USB-C multiport adapter with HDMI turns your MacBook Pro, Dell XPS, or other USB-CTM laptop into a workstation, anywhere you go. The USB Type-C multiport adapter provides 4K HDMI video output, a USB Type-CTM port (data/power), two USB 3.0 Type-A ports, a Gigabit Ethernet port and an SD card reader slot, all through one connection to your laptops USB-C or Thunderbolt 3TM port. Plus, it offers advanced charging through USB Power Delivery 3.0.

Enhance Productivity
The portable docking station connects your laptop to a 4K HDMI monitor (4096 x 2160p) to create a powerful workstation. It can also connect to an ultrawide monitor.
Connect Your Devices
The USB-C to USB 3.0 hub gives you one USB-C port and two USB-A ports to connect your latest and legacy USB devices.
Built-In SD Card Reader
Access your multimedia content with ease. The multiport adapter provides direct access to your SD, SDHCTM and SDXCTM memory cards or microSD cards (with adapter, sold separately).
Charge Your Laptop and Peripherals
With support for USB PD 3.0 (up to 60W), the USB Type-C multiport adapter lets you power and charge your laptop, and power your peripherals when connected to a USB-C power adapter. PD 3.0 features Fast Role Swap to prevent USB data disruption when you switch power sources (USB-C power adapter to bus power).
Reliable Network Connectivity
The Gigabit Ethernet port ensures reliable wired network access.HARDWARE
- 4K Support: Yes
- Bus Type: USB-C
- Chipset ID:
VIA/VLI - VL102
VIA/VLI - VL817
Genesys Logic - GL823K
Parade - PS176
Realtek - RTL8153
- Displays Supported: 1
- Fast-Charge Port(s): No
- Industry Standards:
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
USB 3.0 - Backward compatible with USB 2.0 and 1.1
PERFORMANCE
- Auto MDIXYes
- Compatible Networks: 10/100/1000 Mbps
- Full Duplex Support: Yes
- Maximum Data Transfer Rate:
5 Gbps (USB 3.0)
2 Gbps (Ethernet Full-Duplex)
- Maximum Digital Resolutions:
4096 x 2160p at 24Hz or 3840 x 2160p (HDMI) at 30Hz
UltraWide - 3440 x 1440p at 60 Hz or 2560x1080 at 60Hz
Lower resolutions are also supported. For example,
if the max is 3840 x 2160p (4K), it also supports 2560 x 1600p and 2560 x 1440p.
- Memory Media Type:
Secure Digital Card
SDHC (Secure Digital High Capacity)
SDXC (Secure Digital eXtended Capacity)
microSD (Micro Secure Digital) (adapter required)
microSDHC (Micro Secure Digital High Capacity) (adapter required)
microSDXC (Micro Secure Digital eXtended Capacity) (adapter required)
- Type and Rate: USB 3.0 - 5 Gbit/s
- UASP Support: Yes
CONNECTOR(S)
- Connector Type(s):
1 - USB Type-C (24 pin) USB 3.0 Male
1 - HDMI (19 pin) Female
1 - RJ-45 Female
2 - USB Type-A (9 pin) USB 3.0 Female
1 - SD Slot Female
1 - USB Type-C (24 pin) USB 3.0 Female
SOFTWARE
- OS Compatibility:
Windows 7, 8, 8.1, 10
Mac OS 10.11 to 10.13
Chrome OSTM
SPECIAL NOTES / REQUIREMENTS
- NOTE:
1. Not all USB-C ports support the full functionality of the USB Type-C standard. Ensure that your host USB-C port supports USB Power Delivery 2.0 or higher and DP alt mode.
2. The adapter can connect to a host laptops USB-C port that doesnt support USB Power Delivery 2.0. However, in this configuration if a power adapter is connected to the multifunction adapter, it will not pass power through to your host laptop.
3. A 4K-capable display is required to achieve 3840 x 2160p resolution (4K is also known as 4K x 2K)
4. USB 3.0 is also known as USB 3.1 Gen 1 this connectivity standard offers speeds up to 5Gbps.
5. Your laptop might have specific charging requirements. For example, if your laptop requires exactly 60W of power and an adapter consumes some of the 60W, your laptop might not recognize that it is getting enough power. For more information about Power Delivery, refer to the manufacturer of your hardware.
- System and Cable Requirements:
A host laptop with an available USB-C port (to ensure full adapter functionality, the host USB-C port must support USB Power Delivery 2.0 and DP alt mode)
Optional: USB-C power adapter (for example, your laptops USB-C based power adapter)
POWER
- Power Delivery: 60W
- Power Source: USB-Powered
ENVIRONMENTAL
- Humidity: 5% - 90% RH(Non-condensing)
- Operating Temperature: 0oC to 45oC (32oF to 113oF)
- Storage Temperature: -10oC to 85oC (-14oF to 185oF)
PHYSICAL CHARACTERISTICS
- Cable Length: 10.6 in (270 mm)
- Color: Black
- Enclosure Type: Aluminum
WHATS IN THE BOX
- Included in Package:
1 - multiport adapter
1 - quick-start guide
Item Dimension (L inchxW inchxH inch)
6 x 7 x 2
Weight
1.00lb
Warranty Information
3 Year Warranty

Package Contents:
  • USB-C Multiport Adapter with HDMI - SD Reader - 2xA 1xC - PD 3.0
  • 1 x Quick-start Guide

Features

Package Contents:
  • USB-C Multiport Adapter with HDMI - SD Reader - 2xA 1xC - PD 3.0
  • Quick-start Guide



Environmental Certification:

RoHS
WEEE



Environmentally Friendly:
Yes



Compatibility:
  • Thunderbolt 3 (TB3) laptops/ultrabooks
  • USB-C laptops
  • Ultrabooks
  • Chromebooks
  • Tablets
  • Phone



Brand Compatibility:

Apple
Dell
Lenovo
HP
Microsoft



Country of Origin:
China



Specs

Power Description
Maximum Power Supply Wattage60 W
Physical Characteristics
Weight (Approximate)3 oz
Length10.6"
Product ColorSpace Gray
Height0.60"
Width1.80"
Warranty
Limited Warranty3 Year
Interfaces/Ports
USB Type-CYes
Network (RJ-45)Yes
Host InterfaceUSB Type C
USB Type-AYes
HDMIYes
Total Number of USB Ports3
ThunderboltYes
Number of USB 3.0 Ports2
General Information
Brand NameStarTech.com
Manufacturer Website Addresshttp://www.startech.com
Marketing InformationThis USB-C multiport adapter with HDMI® turns your MacBook Pro, Dell XPS, or other USB-C™ laptop into a workstation, anywhere you go. The USB Type-C multiport adapter provides 4K HDMI video output, a USB Type-C™ port (data/power), two USB 3.0 Type-A ports, a Gigabit Ethernet port and an SD card reader slot, all through one connection to your laptop's USB-C or Thunderbolt 3™ port. Plus, it offers advanced charging through USB Power Delivery 3.0.
Enhance Productivity
The portable docking station connects your laptop to a 4K HDMI monitor (4096 x 2160p) to create a powerful workstation. It can also connect to an ultrawide monitor.
Connect Your Devices
The USB-C to USB 3.0 hub gives you one USB-C port and two USB-A ports to connect your latest and legacy USB devices.
Built-In SD Card Reader
Access your multimedia content with ease. The multiport adapter provides direct access to your SD, SDHC™ and SDXC™ memory cards or microSD cards (with adapter, sold separately).
Charge Your Laptop and Peripherals
With support for USB PD 3.0 (up to 60W), the USB Type-C multiport adapter lets you power and charge your laptop, and power your peripherals when connected to a USB-C power adapter. PD 3.0 features Fast Role Swap to prevent USB data disruption when you switch power sources (USB-C power adapter to bus power).
Reliable Network Connectivity
The Gigabit Ethernet port ensures reliable wired network access.
The DKT30CSDHPD3 is backed by a StarTech.com 3-year warranty and free lifetime technical support.
Note: To ensure full adapter functionality, your laptop's USB-C port must support USB Power Delivery and DP Alt Mode.
Product TypeDocking Station
Product NameUSB-C Multiport Adapter with HDMI - SD Reader - 2xA 1xC - PD 3.0
ManufacturerStarTech.com
Manufacturer Part NumberDKT30CSDHPD3
Packaged Quantity1
Network & Communication
Ethernet TechnologyGigabit Ethernet
Software
Operating System Supported
Technical Information
Number of Displays Supported1
Screen Mode Supported4K
Supported Resolutions
Device SupportedNotebook
Memory Card ReaderYes
Memory Card Supported
Connectivity TechnologyWired
