StarTech HDMI KVM Extender over IP Network - 4K 30Hz HDMI and USB over IP LAN or Cat5e/Cat6 Ethernet [100m/330ft] - Remote KVM Console (235041)

This item is brand-new, factory sealed.

This HDMI KVM extender kit lets you use a keyboard, mouse and monitor to remotely control any computer over your IP-enabled local area network (LAN). Combined with a KVM switch, the KVM console extender can be used with multiple computers. The extender features four USB ports that enable you to connect other USB devices, in addition to your keyboard and mouse.

Supports UHD 4K 30Hz

The HDMI KVM extender delivers astonishing 4K UHD picture quality to your remote display with support for resolutions up to 3840 x 2160p at 30Hz.

Hassle-Free Installation

With a transmitter and a receiver, the KVM extender provides a complete end-to-end solution that supports mounting for tidy installation. Plus, it uses standard CAT5e or CAT6 Ethernet cable, eliminating the expense and hassle of specialized cables and enabling you to use existing network infrastructure.

The extender supports EDID pass-through, ensuring your computer can automatically configure optimal settings for your display over your LAN.

Versatile Configuration Options

The extender uses your local intranet to connect your computers to your remote workstation. You can connect additional receivers (sold separately) to distribute your HDMI signal to multiple displays in your remote location, or combine the source to create a video wall that expands your single video source across multiple displays.

For smaller-scale applications, you can connect the transmitter and receiver units directly over CAT5 or CAT6 cabling up to 330 feet (100 meters).

SV565HDIP is backed by a 2-year warranty and free lifetime technical support.Hardware
Audio
Yes
Chipset ID
ASPEED - AST1520
Daisy-Chain
NoPerformance
Audio Specifications
7.1 Surround Sound (HDMI)
Analog Stereo Sound (3.5 mm)
Analog Mono Microphone (3.5 mm)
Maximum Cable Length
328 ft 100 m
Maximum Data Transfer Rate
12MBps
Maximum Digital Resolutions
3840 x 2160 at 30Hz (4K)
MTBF
60000 hours
Supported Resolutions
3840x2160 (4K) at 30Hz
2560x1600
1920x1200 at 60Hz
1920x1080 (1080p)
1280x720 (720p)
Wide Screen Supported
YesConnector(s)
Local Unit Connectors
1 - HDMI (19 pin)
1 - RJ-45
2 - RJ-11 Female
2 - 3.5 mm Audio Female
2 - 3.5 mm Mini-Jack (3 Position) Female
1 - USB Mini-B (5 pin) Female
Remote Unit Connectors
1 - HDMI (19 pin)
1 - RJ-45
2 - RJ-11 Female
2 - 3.5 mm Audio Female
2 - 3.5 mm Mini-Jack (3 Position) Female
2 - USB Type-A (4 pin) USB 2.0 Female
2 - USB Type-A (4 pin HID Port) USB 1.1 FemaleIndicators
LED Indicators
1 - Transmitter: Green - No Link Blue - Good Link Flashing Blue/Green - Linked but no video
1 - Transmitter: Flashing Orange - Network connection
1 - Receiver: Red - No Link Blue - Good Link Flashing Blue/Red - Linked but no video
1 - Receiver: Flashing Orange - Network connectionPower
Center Tip Polarity
Positive
Input Current
0.6 A
Input Voltage
100 - 240 AC
Output Current
1.5A
Output Voltage
12V DC
Plug Type
M
Power Consumption (In Watts)
18W
Power Source
2 AC Adapters IncludedEnvironmental
Humidity
0% to 80%
Operating Temperature
0^oC to 40^oC (32^oF to 104^oF)
Storage Temperature
-10^oC to 60^oC (14^oF to 140^oF)Physical Characteristics
Color
Black
Material
SteelWhats in the Box
Included in Package
1 - Transmitter Unit
1 - Receiver Unit
2 - Universal Power Adapters (NA, JP, EU, UK, AU/NZ)
2 - Mounting Kits
2 - Ethernet Cables
2 - DB9 Serial Adapters
2 - RJ11 Serial Cables
1 - HDMI Cable (1.2 m)
1 - USB Cable (1.5 m)
8 - Rubber Feet
1 - Plastic Screwdriver
1 - Quick-Start Guide
Cables Included
Yes
DVI Support
Yes
Hot-Key Selection
No
IP Control
No
KVM Ports
1
Max Transfer Distance
100 m (328 ft)
Number of Monitors Supported
1
On-Screen Display
Yes
PC Interface
USB
PC Video Type
HDMIItem Dimension (L"xW"xH")
8 x 15 x 10

Weight
9 lbs

Warranty Information
2 Year Warranty
