StarTech.com HDMI over IP Extender with Video Compression - HDMI over CAT6 Extender - 1080p (221642)

SKU:
18061277
MPN:
221642
Availability:
Out of stock
Stock Update:
06/14/2022 02:01:08 AM PST
  • Main
  • Alternate-Image6
  • Alternate-Image5
  • Alternate-Image4
  • Alternate-Image3
  • Alternate-Image2
  • Alternate-Image1

Out of stock

Stock Update:
06/14/2022 02:01:08 AM PST
Frequently bought together:

Description

This item is brand-new, factory sealed.

The HDMI over IP extender kit makes it easy for you to distribute HDMI to a remote display using your local area network. You can also use additional receivers (ST12MHDLNHR, sold separately) to distribute HDMI to multiple locations.

Save your network bandwidth with video compression
Unlike some video-over-IP solutions that consume your bandwidth, this HDMI over IP kit uses advanced compression to distribute high-quality HDMI video over your network, with minimal bandwidth requirements. Extending your HDMI signal using video compression saves your network resources, avoiding the hassle of a separate video network.

Customize your video distribution with a scalable solution
The HDMI over IP kit can be scaled to meet your specific needs. In a point-to-multipoint setup, you can route your HDMI signal to as many displays as you need, using additional receivers. For additional scalability, you can combine up to 99 different kits to create a multipoint-to-multipoint setup, where you can route different HDMI source signals to different displays. Mounting hardware and IR extenders are included for each transmitter and receiver to ensure tidy, professional installation and hassle-free remote operation.

Get brilliant video at HD 1080p
The HDMI over IP kit maintains your HD video quality, supporting resolutions up to 1080p and making it easy to distribute dynamic digital signage throughout your site to attract customers.
The ST12MHDLNHK is backed by a 2-year StarTech.com warranty and free lifetime technical support.

Hardware
Audio: Yes
Cabling: Cat 5e UTP or better
Daisy-Chain: Yes
Ports: 1
Rack-Mountable: YesPerformance
Audio Specifications: 2-channel
Max Distance: 15 m / 50 ft
Maximum Cable Length: 50 ft 15.2 m
Maximum Digital Resolutions: 1920 x 1080 (1080p) 60Hz
Supported Resolutions: 1920 x 1080 60Hz
Wide Screen Supported: YesConnector(s)
Local Unit Connectors:
1 - HDMI (19 pin) Female Input
1 - RJ-45 Female Output
1 - 3.5 mm Mini-Jack (3 Position) Female
1 - Infrared Female
Remote Unit Connectors:
1 - HDMI (19 pin) Female Output
1 - RJ-45 Female Input
1 - 2.5 mm Mini-Jack (3 Position) Female
1 - Infrared FemaleSpecial Notes / Requirements
Note:
Your router must support IGMP snooping. Please refer to your network switch or router documentation to ensure IGMP snooping is supported and enabled
Each kit requires 6 to 12mbps of local area network bandwidth, when in operationIndicators
LED Indicators:
1 - status LED (transmitter)
1 - status LED (receiver)Power
Input Current: 0.3 A
Input Voltage: 100 - 240 AC
Output Current: 1 A
Output Voltage: 5 DC
Plug Type: USB Mini-B (5 pin)
Power Source: AC Adapter IncludedEnvironmental
Humidity: 0% - 80 %
Operating Temperature: 0oC to 40oC (32oF to 104oF)
Storage Temperature: -10oC to 60oC (14oF to 140oF)Environmental
Humidity: 0% - 80 %
Operating Temperature: 0oC to 40oC (32oF to 104oF)
Storage Temperature: -10oC to 60oC (14oF to 140oF)Whats in the Box
Included in Package:
1 - HDMI over IP transmitter
1 - HDMI over IP receiver
2 - universal power adapters (NA, EU, UK, ANZ)
2 - mounting brackets
2 - CAT5 cables
1 - plastic screwdriver
1 - IR remote control
2 - USB-A to Mini USB-B cable
1 - DB9 to 2.5 mm serial adapter cable
1 - IR blaster
1 - IR receiver
8 - rubber feet
1 - instruction manualItem Dimension (L"xW"xH")
13 x 7 x 3

Weight
2 lbs

Warranty Information
2 Year Warranty

Package Contents:
  • 1 x HDMI Over IP Transmitter
  • 1 x HDMI Over IP Receiver
  • 2 x Universal Power Adapters (NA, EU, UK, ANZ)
  • 2 x Mounting Brackets
  • 2 x CAT5 Cables
  • 1 x Plastic Screwdriver
  • 1 x IR Remote Control
  • 2 x USB-A to Mini USB-B Cable
  • 1 x DB9 to 2.5 mm Serial Adapter Cable
  • 1 x IR Blaster
  • 1 x IR Receiver
  • 8 x Rubber Feet
  • 1 x Instruction Manual

Features

Package Contents:
  • 1 x HDMI Over IP Transmitter
  • 1 x HDMI Over IP Receiver
  • 2 x Universal Power Adapters (NA, EU, UK, ANZ)
  • 2 x Mounting Brackets
  • 2 x CAT5 Cables
  • 1 x Plastic Screwdriver
  • 1 x IR Remote Control
  • 2 x USB-A to Mini USB-B Cable
  • 1 x DB9 to 2.5 mm Serial Adapter Cable
  • 1 x IR Blaster
  • 1 x IR Receiver
  • 8 x Rubber Feet
  • 1 x Instruction Manual



Environmental Certification:

RoHS
WEEE
REACH



TAA Compliant:
Yes



Environmentally Friendly:
Yes



Country of Origin:
Taiwan



Specs

Physical Characteristics
Form Factor
Transmitter Weight (Approximate)7.05 lb
Receiver Width7"
Receiver Height1.10"
Product ColorBlack
Receiver Depth12.20"
Transmitter Depth12.20"
Receiver Weight (Approximate)7.05 lb
Transmitter Height1.10"
Transmitter Width7"
Warranty
Limited Warranty2 Year
Interfaces/Ports
Network (RJ-45)Yes
HDMI OutYes
Number of HDMI Inputs1
HDMI InYes
Number of HDMI Outputs1
Number of Network (RJ-45) Ports2
Video
Maximum Video Resolution1920 x 1080
Graphics ModesFull HD
General Information
Brand NameStarTech.com
Manufacturer Website Addresshttp://www.startech.com
Marketing InformationExtendandcontrolHDMI videooveryour existingLANtocreateastate-of-the-artnetworkofvideodisplaysin a variety ofenvironmentswhere digital signage is required.
Ideal for Universities, Offices, and Restaurants
Reliably Extend Compressed HDMI VideowithBandwidth Efficiency
This extender uses advanced compression to distribute high-qualityHDMI videoover yournetwork, with minimal bandwidth requirements.
With advanced compression technology, broadcasting your video signal requires only 6 - 12 Mbpsof local area network bandwidth, when in operation for each kit.
Flexible & ScalableDeployment Options
TheHDMI over LANextenderoffers many configurations to accommodate your set up.
This HDMI video extender provides four ways to control your video network configurations.
Rotary DIP switches located on the Tx and Rx
Your computer connected to the transmitter or receiver via a serial cable
Over IP using any device equipped with a browser on the same local area network(i.e. tablet, laptop, smartphone)
Infrared (IR)remote control using the includedreceiver
ComprehensiveProduct Testing&ExpertTechnical Support
StarTech.comconducts thoroughcompatibility and performancetestingonallour productstoensure we are meeting orexceeding industry standardsand providinghigh-quality products to our customers. OurlocalStarTech.comTechnicalAdvisorshave broad product expertiseandwork directly with StarTech.comEngineers toprovide support for our customersboth pre and post-sales.
Product TypeVideo Extender Transmitter/Receiver
Product NameHDMI Over IP Extender with Video Compression - 1080p
ManufacturerStarTech.com
Manufacturer Part NumberST12MHDLNHK
Media & Performance
Twisted Pair Cable StandardCategory 6
Media Type SupportedTwisted Pair
Technical Information
Maximum Operating Distance164.04 ft
Number of Input Devices Supported1
Connectivity TechnologyWired
Number of Output Devices Supported1
