TP Link
TP-Link CPE510 - 5GHz N300 Long Range Outdoor CPE for PtP and PtMP Transmission CPE510_3
- SKU:
- 21489329
- MPN:
- cpe510_3
- Availability:
- Usually ships the same or next business day. In stock at our TX warehouse.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 05/02/2026 08:43:06 PM PST
Bulk discount rates
Below are the available bulk discount rates for each individual item when you purchase a certain amount
| Buy 2 | and pay only $66.24 each 66.24 |
| Buy 3 | and pay only $63.80 each 63.8 |
| Buy 4 or above | and pay only $62.55 each 62.55 |
- Stock Update:
- 05/02/2026 08:43:06 PM PST
Description
This item is brand-new, factory sealed.
TP-LINK's 5GHz 300Mbps 13dBi Outdoor CPE, the CPE510 is dedicated to cost effective solutions for outdoor wireless networking applications. With its centralized management application, it is flexible and ideal for point-to-point, point-to-multipoint and outdoor Wi-Fi coverage applications. Professional performance, coupled with user-friendly design, makes CPE510 an ideal choice for both business and home users.
Enterprise Hardware
With Qualcomm Atheros enterprise level chipsets, high gain antennas and high quality material, specially designed enclosure, and PoE power supply, CPE510 is specially designed for outdoor use and can operate flawlessly in almost any climate, with operating temperatures ranging from -30? (-22?) to +70 ? (158?).
Advanced Antenna System
- Built-in High Gain Dual-Polarized Antenna Dedicated metal reflector ensures higher gain and lower noise interference
15km+ Wireless Data Transmission
Specially designed for outdoor uses, ideal for long distance wireless data transmission, covering a range of 15km+ , tested in the field.
15km+ | TP-LINK MAXtream TDMA Technology
As network scale increases, wireless competition and collisions among CPEs and base stations will be so enormous that the real throughput of the network will drop, resulting in a serious impact on end-user experience. To mitigate these effects, the CPE510 uses MAXtream TDMA Technology.
Pharos Control - Centralized Management System
CPE510 also comes equipped with centralized management software that helps users easil manage all the devices in their network from a single PC - Pharos Control. Functions like device discovery, status monitoring, firmware upgrading, and network maintenance can be managed using Pharos Control.
PharOS
User-friendly web-based management system allows professionals to do more specific configurations.
5GHz 300Mbps 13dBi Outdoor CPE CPE510
- Built-in 13dBi Dual-polarized Directional Antenna
- AP / Client / AP Router / AP Client Router (WISP) operation modes
- 6KV Protection
- Weather Proof Enclosure
- 15KV ESD Protection
- Passive PoE Adapter
Package Contents:
- 5GHz 300Mbps 13dBi Outdoor CPE
- 24V 1A Passive PoE Adapter
- Pole Mounting Straps
- AC Power Cord
- Installation Guide
Features
- 5GHz 300Mbps 13dBi Outdoor CPE
- 24V 1A Passive PoE Adapter
- Pole Mounting Straps
- AC Power Cord
- Installation Guide
Additional Information:
Legal Disclaimer:
Actual network speed may be limited by the rate of the product's Ethernet WAN or LAN port, the rate supported by the network cable, Internet service provider factors and other environmental conditions.
Environmentally Friendly:
Yes
System Requirements:
Operating Systems:
- Windows 98SE
- Windows NT
- Windows 2000
- Windows XP
- Windows Vista
- Windows 8
- Windows 7
- Mac OS
- NetWare
- UNIX
- Linux
- Google Chrome
- Safari
- Firefox
Country of Origin:
China
Specs
| Power Description | |
| Input Voltage | 24 V DC |
| Power Consumption | 10.50 W |
| Physical Characteristics | |
| Form Factor | Pole-mountable |
| Height | 1.3" |
| Width | 4.3" |
| Depth | 2.2" |
| Interfaces/Ports | |
| Network (RJ-11) | No |
| VGA | No |
| Ethernet Technology |
|
| Powerline | No |
| USB | No |
| Serial Port | No |
| HDMI | No |
| Audio Line Out | No |
| Management Port | No |
| PoE (RJ-45) Port | Yes |
| Number of Network (RJ-45) Ports | 1 |
| PoE PD Port | Yes |
| General Information | |
| Brand Name | TP-Link |
| Manufacturer Website Address | http://www.tp-link.com/us |
| Marketing Information | TP-LINK's 5GHz 300Mbps 13dBi Outdoor CPE, the CPE510 is dedicated to cost effective solutions for outdoor wireless networking applications. With its centralized management application, it is flexible and ideal for point-to-point, point-to-multipoint and outdoor Wi-Fi coverage applications. Professional performance, coupled with user-friendly design, makes CPE510 an ideal choice for both business and home users. Enterprise Hardware With Qualcomm Atheros enterprise level chipsets, high gain antennas and high quality material, specially designed enclosure, and PoE power supply, CPE510 is specially designed for outdoor use and can operate flawlessly in almost any climate, with operating temperatures ranging from -30? (-22?) to +70 ? (158?). Advanced Antenna System Built-in High Gain Dual-Polarized Antenna Dedicated metal reflector ensures higher gain and lower noise interference 15km+ Wireless Data Transmission Specially designed for outdoor uses, ideal for long distance wireless data transmission, covering a range of 15km+ , tested in the field. 15km+ | TP-LINK MAXtream TDMA Technology As network scale increases, wireless competition and collisions among CPEs and base stations will be so enormous that the real throughput of the network will drop, resulting in a serious impact on end-user experience. To mitigate these effects, the CPE510 uses MAXtream TDMA Technology. Pharos Control - Centralized Management System CPE510 also comes equipped with centralized management software that helps users easil manage all the devices in their network from a single PC - Pharos Control. Functions like device discovery, status monitoring, firmware upgrading, and network maintenance can be managed using Pharos Control. PharOS User-friendly web-based management system allows professionals to do more specific configurations. 5GHz 300Mbps 13dBi Outdoor CPE CPE510 Built-in 13dBi Dual-polarized Directional Antenna AP / Client / AP Router / AP Client Router (WISP) operation modes 6KV Lightning Protection Weather Proof Enclosure 15KV ESD Protection Passive PoE Adapter More from the Manufacturer |
| Product Type | Wireless Bridge |
| Product Name | 5GHz 300Mbps 13dBi Outdoor CPE |
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Manufacturer Part Number | CPE510 |
| Product Model | CPE510 |
| Technical Information | |
| Wireless LAN Standard | IEEE 802.11n |
| UNII Maximum Frequency | 5.85 GHz |
| Wireless Transmission Speed | 300 Mbit/s |
| Data Encryption | Yes |
| Frequency Band | 5.85 GHz |
| Indoor/Outdoor | Outdoor |
| Outdoor Antenna Range | 9.3 Mile |
| Encryption Standard |
|
| ISM Band | Yes |
| UNII Minimum Frequency | 5.15 GHz |
| Antenna Type | Dual Polarized Antenna |
| UNII Band | Yes |
| Wireless Security | <ul><li>WPA</li><li>WPA2</li><li>WPA-PSK (AES/TKIP)</li><li>WPA2-PSK (AES/TKIP)</li><li>64/128/152-bit WEP</li></ul> |
| Features |
|
| Antenna Gain (Isotropic) | 13 dBi |
Warranty Information
