Tripp Lite
Tripp Lite by Eaton series 850VA 450W 120V Standby UPS - 5 NEMA 5-15R Outlets [Surge + Battery Backup], 5-15P Plug, Desktop uninterruptible power supply (bc850r)
- SKU:
- 20589275
- MPN:
- bc850r
- Availability:
- Usually ships the same or next business day. In stock at our PA, SC, TX warehouses.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 12/18/2025 09:12:32 AM PST
Bulk discount rates
Below are the available bulk discount rates for each individual item when you purchase a certain amount
| Buy 2 or above | and pay only $141.20 each 141.2 |
- Stock Update:
- 12/18/2025 09:12:32 AM PST
Description
This item is brand-new, factory sealed.
Tripp Lite 850VA UPS Desktop Battery Backup and Surge Protector, 450W, 5 Outlets, Small Form Factor, Wall Mounting Option, 5ft Cord, 2-Year Warranty (BC850R)- 850VA UPS: 450W uninterruptible power supply provides low-maintenance battery backup and surge protection. Restarts automatically once power is restored, regardless of battery charge level. Features 190 joules of surge protection.
- HOME, OFFICE, AND RETAIL UPS: Built for computing, networking and AV applications. Protect your desktop PC, home entertainment system, wi-fi router, point-of-sale equipment and more. Perfect for kiosks, food service, and light industrial environments.
- SIMPLE SETUP & RELIABLE POWER: Easy set up in minutes. Just plug into a grounded wall outlet, press the power button and connect devices. An audible alarm and red LED indicates low battery or fault. Green LED indicates power and line/battery mode status.
- USER-FRIENDLY DESIGN: Internal battery is easy replaceable with Eaton's AG-075E cartridge. UPS filters out disruptive EMI/ RFI disturbances that can cause hardware damage. A resettable circuit breaker helps prevent dangerous system overloads.
- WALL MOUNT COMPATIBILITY: Small size is suitable for desktop, floor, and wall placement. Keyhole mounting slots on the bottom are spaced in a 100 x 100 mm VESA pattern to enable easy wall mounting. Also allows installation with user-supplied cable ties.
- RELIABLE PRODUCT FULLY BACKED AND SUPPORTED: This product is covered by a 2-Year Limited Manufacturer's Warranty and is supported by Eaton's expert technical support team over phone, web and email.
- Product Dimensions: 14.92 x 6.18 x 10.32 inches
- Item Weight: 7.05 pounds
850VA/450W/120V Battery Backup for PCs and Retail Point-of-Sale Applications
The BC850R standby UPS system provides reliable battery backup and AC power protection against blackouts, brownouts, overvoltages, surges and line noise for computing, networking and point-of-sale equipment in retail, kiosks, food service, and light industrial environments. Its easy to set up in minutes. Just plug the BC850R into a properly grounded wall outlet, press the power button and connect equipment to the UPS outlets. For easy access, the input power cable, outlets, power button and status LEDs are all on the same side.
Allows Time to Back Up Critical Files During a Blackout
During short blackouts and brownouts, the BC850R switches to battery power to keep connected equipment running. This allows you enough time to save data and complete a safe shutdown in case of a longer outage. Incoming utility power keeps the user-replaceable VRLA battery fully charged, so backup power is always available. The BC850R restarts automatically once power is restored, regardless of battery charge level, saving you a costly site visit.
Premium Protection from Surges and Line Noise Helps Your Equipment Perform Better
Rated for 190 joules of surge suppression, the BC850R and its five NEMA 5-15R outlets protect connected devices from the harmful effects of power surges. The BC850R also filters out disruptive electromagnetic interference (EMI) and radio frequency interference (RFI) that can complete a safe shutdown.
Easy Preventative Maintenance and Initial Troubleshooting
The BC850R's self-test capability and user-replaceable internal battery can extend the life of the UPS and minimize disruption to operations. A resettable circuit breaker helps prevent dangerous system overloads.
Audible Alarm and Diagnostic LEDs Keep You Informed 24/7
An audible alarm and a red LED indicate a low battery or fault condition. A green LED indicates power and line/battery mode status.
Hardened Housing Compatible with Versatile Deployment Options
The rugged compact housing allows use in locations with uncontrolled temperature or humidity (operating temperature range: 32 to 122 F / 0 to 50 C). The BC850Rs small size is suitable for desktop or floor placement. Keyhole mounting slots on the bottom enable wall mounting and are spaced in a 100 x 100 mm VESA pattern for mounting to the back of a monitor with the included hardware. Attachment points allow installation on a shelf or beam with user-supplied cable ties. The five-foot power cord with NEMA 5-15P plug connects to any compatible AC outlet.
Package Contents:
- BC850R 850VA Desktop/Surface/Wall Mountable UPS
- 4 x M4 x 12 mm Screws
- 4 x M4 x 20 mm Screws
- Quick Start Guide
Features
- BC850R 850VA Desktop/Surface/Wall Mountable UPS
- 4 x M4 x 12 mm Screws
- 4 x M4 x 20 mm Screws
- Quick Start Guide
Certifications & Standards:
- CAN/CSA-C22.2 No. 107.3
- NOM
- ICES
- UL 1778
Environmentally Friendly:
Yes
Energy Star:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Country of Origin:
Vietnam
Specs
| Power Description | |
| Load Capacity (Watt) | 450 W |
| Input Frequency | 60 Hz |
| Output Power Factor | 0.53 |
| Surge Energy Rating | 190 J |
| Input Voltage | 120 V AC |
| Circuit Breaker | Yes |
| Output Voltage | 120 V AC |
| Load Capacity (VA) | 850 VA |
| Input Current | 7.10 A |
| Waveform Type | Pulse-width Modulated Sine Wave |
| Output Frequency | 60 Hz |
| Physical Characteristics | |
| Form Factor | Desktop/Surface/Wall Mountable |
| Weight (Approximate) | 7.05 lb |
| Height | 3.2" |
| Width | 11" |
| Depth | 7.1" |
| Warranty | |
| Limited Warranty | 2 Year |
| Controls/Indicators | |
| Status Indicators | <p><b>LED Indicators:</b></p><ul><li> Low Battery or Fault Condition</li><li> Power and Line/battery Mode Status</li></ul> |
| Battery Information | |
| Backup/Run Time (Full Load) | 2.50 Minute |
| DC System Voltage | 12 V DC |
| Replaceable Battery | Yes |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Half Load) | 8 Minute |
| Typical Battery Recharge Time | 8 Hour |
| Battery Characteristics | Valve-regulated |
| General Information | |
| Brand Name | Tripp Lite series |
| Manufacturer Website Address | http://www.eaton.com |
| Marketing Information | 850VA/450W/120V Battery Backup for PCs and Retail Point-of-Sale Applications The BC850R standby UPS system provides reliable battery backup and AC power protection against blackouts, brownouts, overvoltages, surges and line noise for computing, networking and point-of-sale equipment in retail, kiosks, food service, and light industrial environments. It's easy to set up in minutes. Just plug the BC850R into a properly grounded wall outlet, press the power button and connect equipment to the UPS outlets. For easy access, the input power cable, outlets, power button and status LEDs are all on the same side. Allows Time to Back Up Critical Files During a Blackout During short blackouts and brownouts, the BC850R switches to battery power to keep connected equipment running. This allows you enough time to save data and complete a safe shutdown in case of a longer outage. Incoming utility power keeps the user-replaceable VRLA battery fully charged, so backup power is always available. The BC850R restarts automatically once power is restored, regardless of battery charge level, saving you a costly site visit. Premium Protection from Surges and Line Noise Helps Your Equipment Perform Better Rated for 190 joules of surge suppression, the BC850R and its five NEMA 5-15R outlets protect connected devices from the harmful effects of power surges. The BC850R also filters out disruptive electromagnetic interference (EMI) and radio frequency interference (RFI) that can complete a safe shutdown. Easy Preventative Maintenance and Initial Troubleshooting The BC850R's self-test capability and user-replaceable internal battery can extend the life of the UPS and minimize disruption to operations. A resettable circuit breaker helps prevent dangerous system overloads. Audible Alarm and Diagnostic LEDs Keep You Informed 24/7 An audible alarm and a red LED indicate a low battery or fault condition. A green LED indicates power and line/battery mode status. Hardened Housing Compatible with Versatile Deployment Options The rugged compact housing allows use in locations with uncontrolled temperature or humidity (operating temperature range: 32° to 122° F / 0° to 50° C). The BC850R's small size is suitable for desktop or floor placement. Keyhole mounting slots on the bottom enable wall mounting and are spaced in a 100 x 100 mm VESA pattern for mounting to the back of a monitor with the included hardware. Attachment points allow installation on a shelf or beam with user-supplied cable ties. The five-foot power cord with NEMA 5-15P plug connects to any compatible AC outlet. More from the Manufacturer |
| Product Type | Standby UPS |
| Product Name | BC850R 850VA Desktop/Surface/Wall Mountable UPS |
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | BC850R |
| Product Model | BC850R |
| Technical Information | |
| Efficiency Detail | 97% (AC Mode) |
| Receptacle Type | NEMA 5-15R |
| Receptacle Detail | 5 x NEMA 5-15R |
| Phase | Single Phase |
| Plug/Connector Type | NEMA 5-15P |
| Cord Length | 5 ft |
| EMI/RFI Noise Filter | Yes |
| Application/Usage |
|
| Features |
|
| Number of Battery & Surge Outlets | 5 |
| Transfer Time | 10 ms |
| Environmental Conditions | |
| Maximum Operating Temperature | 122°F (50°C) |
| Minimum Operating Temperature | 32°F (0°C) |
| Storage Temperature | 5°F (-15°C) - 122°F (50°C) |
| Maximum Operating Elevation | 6561.68 ft |
