Tripp Lite 16-Port Cat5 IP KVM Switch Compact 1+1 User Rackmount (B072-016-1-IP)

(No reviews yet) Write a Review
SKU:
18129229
MPN:
b072-016-1-ip
Availability:
Out of stock
Stock Update:
01/31/2023 11:16:02 AM PST
  • Main
  • Right
  • Rear
  • Front
  • Alternate-Image1

Out of stock

Stock Update:
01/31/2023 11:16:02 AM PST

Description



This item is brand-new, factory sealed.

Tripp Lite's B072-016-1-IP is Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases. This 16-Port NetCommander 1U Rackmount Cat5 KVM over IP Switch is the next generation of our cost-effective, feature-rich KVM switches. It's sleek, 1U design and compact size features RJ45 connection ports that utilize inexpensive Cat5 patch cables, reducing the amount of cable clutter normally found with traditional KVM cabling, as well as the ability to log in from anywhere via the Internet. Easily switch between CPU's with hot key commands, the built-in On-Screen Display (OSD) menu or the remote console toolbar. Cascadability allows connection to up to 256 computers. Compatible with PS/2 and USB computers, VGA, SVGA or XGA monitors, as well as the following OS platforms: DOS, Windows (all versions), LINUX, UNIX, HP UX, and SUN. 1-year limited warranty.



Package Contents:
  • NetCommander B072-016-1-IP 16-Port KVM Over IP Switch
  • 16-Port NetCommander 1U Rackmount Cat5 KVM over IP Switch
  • Rackmount Bracket kit
  • 6ft Power Cord
  • 6ft Serial Cable

Features

Package Contents:
  • NetCommander B072-016-1-IP 16-Port KVM Over IP Switch
  • 16-Port NetCommander 1U Rackmount Cat5 KVM over IP Switch
  • Rackmount Bracket kit
  • 6ft Power Cord
  • 6ft Serial Cable



Environmental Certification:
RoHS



TAA Compliant:
Yes



Environmentally Friendly:
Yes



Country of Origin:
Taiwan



Specs

Power Description
Input Voltage Range120V AC to 230V AC
Input Voltage
Physical Characteristics
Form FactorRack-mountable
Weight (Approximate)4.70 lb
Height1.8"
Width17"
Rack Height1U
Depth9"
Warranty
Limited Warranty3 Year
Interfaces/Ports
VGAYes
Number of USB Ports3
Network (RJ-45)Yes
USBYes
Number of VGA Ports1
Number of Network (RJ-45) Ports20
Video
Maximum Video Resolution1920 x 1200
Graphic ModeUXGA
General Information
Brand NameTripp Lite
Manufacturer Website Addresshttp://www.tripplite.com
Marketing InformationTripp Lite's B072-016-1-IP KVM Switch is the optimal solution for controlling up to 16 computers/servers locally, from across the room, down the street or around the globe on a network or the Internet.
This KVM switch can be accessed and controlled remotely, so there's no need to travel to the server room or network closet. A Java-based application allows access via web browser from any secure IP connection; a non-browser client that can bypass browser-related Java Security prompts is available.
The B072-016-1-IP uses inexpensive, user-supplied Cat5e/6/6a cabling with Server Interface Units (sold separately) so you can connect computers/servers located up to 100 ft. away from the switch. This switch features dual Ethernet ports; if one fails, the other takes over, keeping remote access uninterrupted. Users can switch easily between the 16 ports using an on-screen display (OSD), hotkey commands or a remote toolbar. Multi-level password protection prohibits unauthorized users from accessing connected computers, and a local user and a remote user can each log on and access different ports simultaneously.
Two serial ports allow control of serial-manageable devices such as IP PDUs, firewalls and routers; individual ports can be assigned to an IP PDU port to power on/off the server connected to that port. This KVM switch is compatible with Windows and Linux operating systems, and provides remote access using a Windows computer. It supports VGA video resolutions up to 1920 x 1080 @ 60 Hz. Heavy-duty steel housing stands up to frequent use.
Virtual Media allows an .iso file to be mounted to a target server and accessed as if it were stored directly on it. Virtual Media data transfer rates up to 12Mbps are supported when using a B078-101-USB2 Server Interface Unit. Other features include RADIUS and LDAP/S authentication, system-sent SNMP messaging and an event log that tracks logins, reboots and network setting changes.
Free NetCommander-AXS Management Software is available to access and control all of your Tripp Lite NetCommander IP KVM switches (B070 and B072 series). From a single interface, you can access server ports on any of your KVM switches, power cycle or power on/off outlets of IP PDUs and manage KVM settings. This software can be downloaded free of charge from the model support page for the B072-016-1-IP.
Features
Saves Space and Money
Mounts in a standard 19 in. rack
Inexpensive Cat5e/6/6a cabling lets you locate servers up to 100 ft. from the switch
Use a Server Interface Unit, B078-101-USB-1 (for USB) or B078-101-PS2 (for PS/2) with each server to be connected with Cat5 cable; use a B078-101-USB2 to support Virtual Media data transfer rates up to 12Mbps
To convert DisplayPort or HDMI computers to VGA, use Tripp Lite adapters P134-06N-VGA-V2 or P131-06N. Maximum video resolutions using adapters may vary.
IP Remote Access for Fewer Trips to the Server Room
Control this KVM switch over IP: remote access means there's no need to travel to the server room or network closet
Java-based application allows Windows computers to control a target server via web browser from any location over a secured IP connection
A non-browser client is available that allows Windows computers to remotely access the KVM without the need for a browser and without the need to install Java
1 local + 1 remote user can access different ports concurrently; up to 5 users can share a single remote session
Supports both IPv4 and IPv6
Product TypeKVM Switchbox
Product Name16-Port Cat5 1+1 User 1U Rack-Mount VGA USB KVM Switch with IP Remote Access
ManufacturerTripp Lite by Eaton
Manufacturer Part NumberB072-016-1-IP
Product ModelB072-016-1-IP
Product LineNetCommander
Technical Information
Daisy Chain SupportedYes
Number of Remote Users Supported1
Number of Computers Supported16
KVM TechnologyDigital
Maximum Operating Distance100 ft
Number of Local Users Supported1
