Tripp Lite Isobar Surge Protector Rackmount Metal 12 Outlet 15' Cord 1U RM (IBAR-12-ULTRA) ISOBAR12ULTRA
- SKU:
- 18128588
- MPN:
- IBAR-12-ULTRA
- Availability:
- Usually ships the same or next business day. In stock at our IL, PA, TX warehouses.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 05/18/2024 09:12:03 PM PST
Bulk discount rates
Below are the available bulk discount rates for each individual item when you purchase a certain amount
Buy 2 - 3 | and pay only $150.31 each 150.31 |
Buy 4 or above | and pay only $142.30 each 142.3 |
- Stock Update:
- 05/18/2024 09:12:03 PM PST
Description
This item is brand-new, factory sealed.
Tripp Lites ISOBAR12ULTRA offers network-grade surge and noise suppression in a versatile all-metal multi-mount cabinet. Detachable mounting flanges are configurable for rackmount, wallmount and under-counter installation. Uses only 1 rack space (1U) when installed in any 19 inch EIA standard rack. Features the highest level of AC surge and EMI/RFI noise suppression of all Tripp Lite rackmount surge suppressors. Outlets are arranged in exclusive isolated filter banks to limit noise interaction among connected items. Includes 12 outlets (2 front/10 rear), 15 ft AC power cord and guarded power switch to reduce the risk of accidental shutoff. Diagnostic LEDs indicate AC present, line fault and protection status.SYSTEM OVERVIEWVoltage compatibility -- 120 VACFrequency compatibility -- 50/60 HzOUTPUTOutput volt amp capacity (amps) -- 15Output watts -- 1800Outlet quantity / type -- 12(2 front NEMA 5-15R / 10 rear)INPUTInput connection type -- NEMA 5-15P input plugInput cord length (ft.) -- 15 ft.Input cord length (m) -- 4.6Recommended Electrical Service -- 120V (110-125V)LEDS ALARMS AND SWITCHESDiagnostic LEDs -- PROTECTION PRESENT (green), LINE FAULT (red) and LINE OK (green)Switches -- Red illuminated power switch controls power to all outletsLocking switch cover -- Transparent locking switch cover prevents accidental shutoffSURGE / NOISE SUPPRESSIONProtection modes -- Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppressionAC suppression joule rating -- 1280 joulesClamping voltage (RMS) -- 140VFeatures
Package Contents:
Yes
China
- Isobar 12-Outlets 120V Surge Suppressor
- Warranty Information
- Instruction Manual
Certifications & Standards:
- UL1449 (let through rating 330V)
- UL1283
- cUL
- IEEE 587 category A and B
Additional Information:
- Transparent locking switch cover prevents accidental shutoff
- 2 front and 10 rear receptacles
Environmentally Friendly:
Yes
Compatibility:
- Internetworking Equipment
- Computers
- Telecommunications Systems
- Audio/Video Systems
- Security & Sound Reinforcement
Country of Origin:
China
Specs
Power Description | |
Maximum Surge Current | 96 kA |
Surge Energy Rating | 3840 J |
Power Handling | 1800 VA |
Input Voltage | 120 V AC |
Circuit Breaker | Yes |
Output Voltage | 120 V AC |
Maximum Line Current | 15 A |
Physical Characteristics | |
Weight (Approximate) | 4.60 lb |
Product Color | Black |
Power Cord/Cable Length | 15 ft |
Height | 1.8" |
Color Family | Black |
Width | 17.5" |
Depth | 4" |
Warranty | |
Limited Warranty | Lifetime |
Controls/Indicators | |
Status Indicators | <li>Line OK</li> <li>Line fault</li> <li>Protection present</li> |
General Information | |
Brand Name | Tripp Lite by Eaton |
Manufacturer Website Address | https://tripplite.eaton.com/ |
Marketing Information | Tripp Lite's ISOBAR12ULTRA offers network-grade surge and noise suppression in a versatile all-metal multi-mount cabinet. Detachable mounting flanges are configurable for rackmount, wallmount and under-counter installation. Uses only 1 rack space (1U) when installed in any 19 inch EIA standard rack. Features the highest level of AC surge and EMI/RFI noise suppression of all Tripp Lite rackmount surge suppressors. Outlets are arranged in exclusive isolated filter banks to limit noise interaction among connected items. Includes 12 outlets (2 front/10 rear), 15 ft AC power cord and guarded power switch to reduce the risk of accidental shutoff. Diagnostic LEDs indicate AC present, line fault and protection status. Lifetime warranty with $25,000 Ultimate Lifetime Insurance (USA & Canada Only) coverage .PLUG/OUTLETS: Input: NEMA 5-15P/Output: 12 NEMA5-15R (2 front & 10 rear)ELECTRICAL: 120V AC, 50/60Hz, 15A (Requires NEMA 5-15R wall receptacle)FORMAT: Supports 19 in. rackmount (uses 1 rack space/1U), wallmount, under-counter and more More from the Manufacturer |
Product Type | Surge Suppressor/Protector |
Product Name | Isobar 12-Outlets 120V Surge Suppressor |
Manufacturer | Tripp Lite by Eaton |
Manufacturer Part Number | ISOBAR12ULTRA |
Technical Information | |
Plug/Connector Type | NEMA 5-15P |
Receptacles | 12 x NEMA 5-15R |
Protection Type | Surge |
