Tripp Lite Ethernet Switch Unmanaged 16Port Industrial 10/100/1000 Mbps DIN (ngi-u16)

This item is brand-new, factory sealed.

• Industrial-grade switch expands Ethernet to factory floors and environments with space constraints & wide temperature ranges. Sixteen auto-negotiable 10/100/1000 Mbps RJ45 ports connect over LAN.
• Industrial-grade switch supports operating temperature range of -40 to 75C (-40 to 167F).
• Easy-to-read LEDs indicate connection and activity status for all Ethernet ports
• Plug-and-play operation with no software or configuration required before use
• 3-year limited warranty

• Brand: Tripp Lite
• Item Weight: 2.2 pounds
• Package Dimensions: 9.17 x 7.2 x 2.44 inches
• Manufacturer: TRIPP LITE

16-Port Unmanaged Gigabit Ethernet Switch Connects Your Devices to a LAN This Tripp Lite network switch connects devices, such as computers, printers and servers, to a local area network (LAN) and allows them to communicate over the network. Sixteen auto-negotiating 10/100/1000 Mbps ports send data only to the devices designated to receive it, which improves the efficiency and potential throughput of the network. Rugged Metal Housing Built to Last in Harsh Environments The NGI-U16 adds Gigabit Ethernet capacity to your industrial and commercial applications, such as factories, construction sites, supply rooms and warehouses. You can share large bandwidth-intensive files, such as CAD drawings and videos, improving efficiency and cutting costly downtime. The industrial-grade switch with its rugged high-strength case withstands vibration, shock and free fall. It can also operate in extreme temperatures ranging from -40 degrees to 167 degrees Fahrenheit. Unmanaged Switch for Plug-and-Play Use Because it is an unmanaged switch, the NGI-U16 does not require configuration before use. LEDs indicate when the switch is powered on and which Ethernet ports are showing activity. The NGI-U16 supports MAC address auto-learning and auto-aging for efficient routing, as well as automatic MDI/MDI-X crossover detection for plug-and-play functionality. IEEE 802.3x flow control allows smooth transmission of large files. Pre-Installed DIN Rail Clip Allows for Convenient Installation The switch may be DIN mounted using the pre-installed rail clip, which mounts firmly to any standard 35 mm DIN rail. A 2-pin 12-48VDC terminal block supplies power input. Device power must be supplied by LPS (Limited Power Source) circuit. TAA-Compliant for GSA Schedule Purchases The NGI-U16 is compliant with the Federal Trade Agreements Act (TAA), which makes it eligible for GSA (General Services Administration) Schedule and other federal procurement contracts.

• NGI-U16 Ethernet Switch
• DIN Rail-mounting Clip (Pre-installed)
• Owner's Manual
