Tripp Lite UPS Smart 1200VA 700W Rackmount Tower Battery Back Up LCD AVR 120V USB DB9 RJ45 (SMART1200LCD)
(No reviews yet)
Write a Review
- SKU:
- 18061151
- MPN:
- smart1200lcd
- Availability:
- Usually ships the same or next business day. In stock at our CA, GA, IL, PA warehouses.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 12/13/2025 07:22:29 AM PST
Bulk discount rates
Below are the available bulk discount rates for each individual item when you purchase a certain amount
| Buy 3 or above | and pay only $399.81 each 399.81 |
- Stock Update:
- 12/13/2025 07:22:29 AM PST
Description
This item is brand-new, factory sealed.
Tripp Lites SMART1200LCD Line-Interactive Digital UPS System offers voltage regulation, surge suppression and long-lasting battery support for personal computers, network workstations, home entertainment systems and media centers. Internal UPS circuits support entry-level PCs or individual VCR/DVR components during power failures. Prevents data loss, viewing interruptions, lost recordings and loss of component programming. Automatic Voltage Regulation (AVR) circuits regulate brownouts and overvoltages from 75V to 147V back to usable levels without using battery power. Offers complete power protection with support for upright tower, flat shelfmount or 2U rackmount installation in an attractive all-black cabinet design. Includes 8 battery-supported outlets. Built-in USB and DB9 serial ports enables optional unattended system shutdown without data loss in case of extended power failure cabling included. PowerAlert Software available via free download from www.tripplite.com. HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Built-in single-line RJ-45 jacks offer protection for equipment with single-line tel/DSL or network Ethernet connection. Built-in audible alarm and large LCD front panel voltage display indicates line power status, battery power status, battery low/replace status and voltage boost operation. 1200VA/700W power-handling capacity supports entry-level PCs, home entertainment systems, network workstations and audio/video components. Offers 4 min. battery runtime with a full load of 1200VA/700W and 12 min. with a half load of 600VA/350W. 2-year warranty 250,000 connected equipment insurance (USA Canada only).- LCD display indicates input voltage, battery capacity and a variety of operating conditions. Display is rotatable for easy viewing whether UPS is in vertical or horizontal position- SMART1200LCD Digital Uninterruptible Power Supply offers voltage regulation, surge suppression and long-lasting battery support during blackouts- Supports entry-level PCs or single VCR/DVR components during blackouts- Regulates brownouts and overvoltages from 75V to 147V back to usable levels without using battery power- 8 UPS battery-supported outlets- Included DB9 serial and USB monitoring ports and cables enable unattended shutdown in case of extended power failure- HID-compliant USB port enables full integration with built-in power management and auto shutdown features of Windows, Linux and Mac OS X- PowerAlert Software available via free download from www.tripplite.com- Set of phone/network protection jacks protects a single dialup/DSL phone line or network Ethernet connection- 1200VA/700W power handling ability supports a variety of sensitive computer, home theater and other equipment- 4 min. full load runtime (1200VA/700W); 11 min. half-load runtime (600VA/350W)- Cabinet adapts to tower or rackmount shelf format. Rackmount (2U) format requires an optional shelf, available separatelySystem overview - 1200VA line-interactive UPS systemVoltage compatibility - 120 VACFrequency compatibility - 60Output volt amp capacity (VA) - 1200Output watt capacity (watts) - 700Output nominal voltage - 120 VACOutput voltage regulation - BATTERY MODE: PWM sine wave 115V +/-5%Output frequency regulation - LINE MODE: Passes line frequency of 60Hz +/-10% BATTERY MODE: Inverter output regulated to 60Hz +/-0.5HzFeatures
Package Contents:
Taiwan
- SmartPro 1200 VA Rack-mountable Tower Digital UPS
- SMART1200LCD Digital UPS
- USB, DB9 and phone cabling
- Mounting hardware
- Manual with warranty information
Certifications & Standards:
- Tested to UL1778 (USA)
- CSA (Canada)
- NOM (Mexico)
- Class B (EMI)
- FCC Part 68
- Industry Canada (US & Canada)
Additional Information:
- Switches: Includes 2 front panel switches one main on/off power switch and one dual-function "alarm cancel"/"self test" button
- WatchDog compatibility: Yes, compatible with Tripp Lite's Watchdog system service to restore operation to locked equipment through soft reboot of application / OS or hard power off/on reboot of connected equipment - ideal for unattended kiosk applications
- Low voltage transfer to battery power: Switches to battery power as line voltage decreases to 75V or less, switches back to AC mode as line voltage increases to 79V or higher
- High voltage transfer to battery power: Switches to battery mode as line voltage increases to 147V or higher, switches back to AC mode as line voltage decreases to 143V or lower
- Cold Start: Yes, inverter can be "cold started" to enable temporary AC output during a power failure
- Typical Applications: Entry-level PCs, networked workstations, point-of-sale equipment, small business phone systems, audio/video equipment and home theater systems. Ideal for sensitive electronic applications in areas where brownout conditions are common
- Internal UPS circuits support entry-level PCs or individual VCR/DVR components during power failures
- Prevents data loss, viewing interruptions, lost recordings and loss of component programming
- Automatic voltage regulation (AVR) circuits regulate brownouts and overvoltages from 75V to 147V back to usable levels without using battery power
- HID-compliant USB interface enables full integration with built-in power management and auto shutdown features of Windows, Mac OS X and Linux
- Display is rotatable for easy viewing whether UPS is in vertical or horizontal position.
- Cabinet adapts to tower or rackmount shelf format
Country of Origin:
Taiwan
Specs
| Power Description | |
| Load Capacity (Watt) | 700 W |
| Surge Energy Rating | 870 J |
| Input Voltage | 110 V AC |
| Circuit Breaker | Yes |
| Output Voltage | 120 V AC |
| Load Capacity (VA) | 1200 VA |
| Waveform Type | Pulse-width Modulated Sine Wave |
| Physical Characteristics | |
| Form Factor | Tower |
| Weight (Approximate) | 25.13 lb |
| Product Color | Black |
| Height | 17.3" |
| Color Family | Black |
| Width | 3.5" |
| Depth | 10.5" |
| Rack Height | 2U |
| Warranty | |
| Limited Warranty | 3 Year |
| Controls/Indicators | |
| Status Indicators | <p><b>Front panel LCD screen with blue backlight offers:</b></p><ul><li>Continuous input line voltage data</li><li>Line power</li><li>Battery power</li><li>Battery charge level</li><li>Voltage regulation operation</li></ul> |
| Interfaces/Ports | |
| USB | Yes |
| Serial Port | Yes |
| Battery Information | |
| Backup/Run Time (Full Load) | 4 Minute |
| Battery Life | 6 Year |
| Backup/Run Time (Half Load) | 14.30 Minute |
| Typical Battery Recharge Time | 8 Hour |
| General Information | |
| Brand Name | Tripp Lite series |
| Manufacturer Website Address | http://www.eaton.com |
| Marketing Information | The SMART1200LCD SmartPro LCD 120V, 1200VA/700W Line-Interactive Uninterruptible Power Supply provides battery backup and AC power protection against blackouts, brownouts, power surges and line noise that can damage electronics or destroy data. Ideal for backing up your desktop computer or audio/visual components, this line-interactive UPS switches to battery backup mode in milliseconds to keep your connected equipment running long enough to save files and shut down safely with no data loss. Eight NEMA 5-15R outlets protect against surges, as well as provide up to 14.3 minutes of UPS battery support at half load (350W) and 4.0 minutes of support at full load (700W). Automatic voltage regulation (AVR) corrects severe undervoltages as low as 75V and overvoltages as high as 147V without using any battery power. EMI/RFI noise filtering improves your equipment's performance and prevents damage. A 870-joule surge suppression rating protects your equipment from harmful power surges. NEMA 5-15P plug with 6-ft. (1.83 m) cord connects to any NEMA 5-15R socket. Large rotatable LCD screen shows real-time input voltage, overload, AVR and battery statuses at a glance. Alarm sounds to indicate power loss or low battery. With Tripp Lite's free PowerAlert software (available via free web download), the SMART1200LCD enables safe unattended system shutdown and file saves in case of a prolonged power failure. Reliable Battery Backup Provides 1200VA/700W high-performance power protection for desktop computers, audio/video components, media centers and other electronics Supports 50% load (350W) up to 12 minutes and full load (700W) up to 4 minutes Audible alarm indicates loss of utility power or low battery Battery access door enables hot-swappable, user-replaceable internal batteries Optimized Outlets 8 NEMA 5-15R outlets provide battery backup and protect against surges or spikes that can harm equipment or data Automatic Voltage Regulation (AVR) Corrects undervoltages as low as 75V and overvoltages as high as 147V without drawing battery backup power Rotatable LCD Status Screen Large LCD screen shows real-time input voltage, overload, AVR and battery statuses Rotates for easy viewing in both horizontal and vertical installations Dimmer option controls brightness level AC Line, Tel/DSL and Ethernet Surge Suppression Surge suppression rating of 870 joules protects connected equipment and data from harmful power surges Built-in RJ-45 jacks protect single-line tel/DSL or network Ethernet connection More from the Manufacturer |
| Product Type | Line-interactive UPS |
| Product Name | SmartPro 1200 VA Rack-mountable Tower Digital UPS |
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | SMART1200LCD |
| Product Model | SMART1200LCD |
| Product Line | SmartPro |
| Technical Information | |
| Receptacle Type | NEMA 5-15R |
| Receptacle Detail | 8 x NEMA 5-15R |
| Plug/Connector Type | NEMA 5-15P |
| Cord Length | 6 ft |
| Dataline Protection | RJ-45 |
| Transfer Time | 4 ms |
| Environmental Conditions | |
| Thermal Dissipation | 71.42 W |
| Maximum Operating Temperature | 122°F (50°C) |
