Ubiquiti 10G PoE++ Adapter [60W] (uacc-poe----10g)
(No reviews yet)
Write a Review
- SKU:
- 21377740
- MPN:
- uacc-poe----10g
- Availability:
- Out of stock
- Stock Update:
- 11/02/2026 03:56:06 AM PST
- Stock Update:
- 11/02/2026 03:56:06 AM PST
Frequently bought together:
Description
This item is brand-new, factory sealed.
An adapter that can power UniFi PoE+++ devices reduce dependency on PoE switch power and provide a Multi-Gigabit LAN connection. Delivers up to 90W of PoE+++ Surge peak pulse and overcurrent protection Contains RJ45 data input AC cable with earth ground and PoE+++ output LED indicator for status monitoring Supports wall mount DIN rail and floating mount.Features
NDAA Compliant:
Yes
Yes
Package Contents:
- 10G PoE++ Adapter (60W)
- Power Cable
Certifications & Standards:
Supported IEEE Standards:
- 802.3af (PoE 15.4 W)
- 802.3at (PoE+ 30 W)
- 802.3bt Type 3 (PoE++ 60 W)
Certifications:
- CE
- FCC
- IC
- UL
- UKCA
- KC
- CCC
Additional Information:
- 4-pair Powering: Pins 1, 2, 4, 5 (+) and 3, 6, 7, 8 (-)
- Clamping Protection: 11V Data, 60V power
- Data In / PoE: RJ45 Shielded Socket
- Inrush Current: <150A peak at 230V AC
- Efficiency: >88%
- Switching Frequency: 65 kHz
- Output Ripple: 1% Max.
- Line Regulation: ≤ 2%
- Load Regulation: ≤ 5%
- Max. PoE+ Wattage per Port by PSE: 60W
- Max. Surge Discharge: 1500A (8/20 µs) power
- Peak Pulse Current: 36A (10/1000 µs) data
- Response Time: <1 ns
- Shunt Capacitance: <5 pF data
- Surge Protection: Difference and common mode
- Ambient Storage Temperature: -30 to 70°C (-22 to 158° F)
- Ambient Operating Temperature: 0 to 40° C (32 to 104° F)
- Ambient Operating Humidity: 10 to 95% noncondensing
Compatibility:
UI Products:
- E7
- E7-Campus
- E7-Campus-Indoor
- E7-Audience
- E7-Audience-Indoor
- U7-Pro-XGS
- U7-Pro-XG
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Waste Electrical and Electronic Equipment Directive (WEEE)
Specs
| Power Description | |
| Maximum Output Voltage | 54 V DC |
| Maximum Output Current | 1.12 A |
| Maximum Output Power | 60 W |
| Input Voltage |
|
| Maximum Input Current | 1.50 A |
| Physical Characteristics | |
| Weight (Approximate) | 7.41 oz |
| Height | 4.2" |
| Width | 2.5" |
| Depth | 1.3" |
| Interfaces/Ports | |
| Output Ports | 1 x PoE++ |
| Input Ports | 1 x RJ-45 |
| General Information | |
| Brand Name | Ubiquiti |
| Manufacturer Website Address | http://www.ui.com |
| Marketing Information | An adapter that can power UniFi PoE++ devices, reduce dependency on PoE switch power, and provide a Multi-Gigabit LAN connection. Delivers up to 60W of PoE++ Surge, peak pulse, and overcurrent protection Contains RJ45 data input, AC cable with earth ground, and PoE++ output LED indicator for status monitoring |
| Product Type | PoE++ 10G Injector |
| Product Name | 10G PoE++ Adapter (60W) |
| Manufacturer | Ubiquiti Inc. |
| Manufacturer Part Number | UACC-PoE++-10G |
| Technical Information | |
| Protection Type |
|
Warranty Information
All Items are Brand New, Factory Sealed and come with a standard warranty. [Read our policies]
