ViewSonic LS625X Laser Short Throw DLP Projector - 4:3 - White

This item is brand-new, factory sealed.

Featuring 1024x768 XGA resolution and 3,200 lumens of brightness, the ViewSonic LS625X short throw laser projector is an ideal projection solution for education environments. Designed with a laser phosphor light source lasting up to 20,000 hours, and a sealed optical engine with a waveform air filter that protects against dust and moisture, this projector delivers long-term, virtually maintenance-free usage for any classroom. With its 0.49 short throw ratio and horizontal/vertical keystoning, the LS625X makes installation a hassle-free experience. Whats more, the short throw ratio allows you to place the projector just a few feet from a wall or screen to give you a huge image for less cost than a comparably sized display. Crestron and AMX certification delivers network management capabilities, while exclusive SuperColor technology offers a wide color range for true-to-life images in any classroom.

BRIGHT IMAGES IN ANY ENVIRONMENT

Packed with 3,200 lumens and a high contrast ratio, this projector produces bright images in nearly any environment.


LARGE IMAGES IN SMALL SPACES

A short throw lens enables large images to be projected from short distances in small rooms. In addition, any blinding lights in front of the presenter, distracting shadows on the projected image, or glaring hotspots on the screen, are all eliminated because the projectors light source is closer to the projection surface.


LONG-LASTING LASER PHOSPHOR LIGHT SOURCE

Designed with a laser phosphor light source lasting up to 20,000 hours*, this projector delivers long-term, virtually maintenance-free usage for a lower overall total cost of ownership.

DISPLAY
TYPE
DLP Lamp
RESOLUTION TYPE
XGA (1024x768)
RESOLUTION
1024 x 768
BRIGHTNESS (LUMENS)
3,200 ANSI
DISPLAY SIZE (IN.)
60 - 300 in. / 1.5 - 7.6 m
THROW DISTANCE
2.1 - 10.4 ft / 0.6 - 3.2 m
THROW RATIO
0.49
KEYSTONE
Vertical (+/- 40^o)
LENS
Fixed Zoom
LIGHT SOURCE LIFE, NORMAL (HOURS)
20000
LIGHT SOURCE LIFE, DYNAMIC ECO-MODE (HOURS)
20000
COLOR DEPTH
1.07B Color (R/G/B 10bit)
ASPECT RATIO
4:3
VIDEO SIGNAL
FREQUENCY HORIZONTAL
15K to 102KHz
FREQUENCY VERTICAL
23 to 120Hz
COMPATIBILITY
PC RESOLUTION (MAX)
1920 x 1080
MAC RESOLUTION (MAX)
1920 x 1080
CONNECTOR
ETHERNET LAN (RJ45)
1
3.5MM 12V TRIGGER
1
3.5MM AUDIO OUT
1
3.5MM AUDIO IN
1
CONTROL (RS232)
1
HDMI 1.4
1
HDMI 1.4 (WITH HDCP 1.4)
1
VGA IN
2
VGA OUT
1
COMPOSITE RCA VIDEO IN
1
S-VIDEO IN
1
MINI USB
1
AUDIO
INTERNAL SPEAKERS
10W (x1)
POWER
CONSUMPTION (TYPICAL)
305W
STAND-BY
<0.5W
CONTROLS
PHYSICAL CONTROLS
Power, keystone/arrow keys, left/blank, menu/exit, right/panel key lock, mode/enter, auto, source
ON SCREEN DISPLAY
Display, Image, Power Management, Basic, Advanced, System, Information (See user guide for full OSD functionality)
OPERATING CONDITIONS
TEMPERATURE
32-104^oF (0 - 40^oC)
HUMIDITY (NON-CONDENSING)
0-90%
ADDITIONAL HARDWARE
KENSINGTON LOCK SLOT
1 GENERAL
AV CONTROL
AMX Certified, Crestron Certified, PJ Link Certified
REGULATIONS
FCC, cTUVus, ROHS
PACKAGE CONTENTS
LS625X projector, power cable, VGA cable, remote control, Quick Start Guide
RECYCLE/DISPOSAL
Please dispose of in accordance with local, state or federal laws.
Item Dimension (L"xW"xH")
16 x 6 x 12
Weight
13.60 LB


Package Contents:

• Power Cable
• VGA Cable
• Remote Control
• Quick Start Guide
