Asus RT-AX86U Wi-Fi 6 IEEE 802.11ax Ethernet Wireless Router (90ig05f1-ma1g1v)

This item is brand-new, factory sealed.

AX5700 Dual Band WiFi 6 Gaming Router, PS5 compatible, Mobile Game Mode, Lifetime Free Internet Security, Mesh WiFi support, 2.5G Port, Gaming Port, Adaptive QoS, Port Forwarding


New-generation WiFi 6 - Enjoy ultrafast speeds up to 5700 Mbps with the latest WiFi 6 (802.11ax) and 160MHz channels

Mobile Game Mode - Minimize lag and latency for mobile gaming with just a tap on the ASUS Router app

True 2 Gbps wired and wireless speeds - Aggregated 2 Gbps WAN connections, wired 2.5 Gbps port and WiFi 6

ASUS AiMesh support Create a flexible, seamless whole-home mesh network with AiMesh-compatible routers

Commercial-grade home network security Lifetime free ASUS AiProtection Pro, powered by Trend Micro, with WPA3 and advanced Parental Controls to protect your home


Your Winning Choice for Mobile Gaming!

Enjoy the fastest, smoothest WiFi gaming connections ever with the ASUS RT-AX86 Series dual-band WiFi 6 router. It delivers ultrafast WiFi speeds up to 5700 Mbps**, and is packed with advanced technology, including Mobile Game Mode for a lag-free, low-latency mobile gaming experience.


Ultrapowerful WiFi 6

Lower latency / Faster speeds / Energy efficient / Longer range

RT-AX86 Series brings you all the benefits of WiFi 6 (802.11ax), and works perfectly with all your existing WiFi devices! ***


Boost Your Mobile Gaming

Minimize lag and latency for mobile gaming with just a tap on the ASUS Router app.


** Actual data throughput and WiFi coverage will vary from network conditions and environmental factors, including the volume of network traffic, building material and construction, and network overhead, result in lower actual data throughput and wireless coverage.

*** To benefit from WiFi 6 features, the WiFi client needs to be WiFi 6 capable. Network Standard
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
IPv4
IPv6 Product Segment
AX5700 ultimate AX performance : 861+4804Mbps AX technology
Yes Data Rate
802.11a : up to 54 Mbps
802.11b : up to 11 Mbps
802.11g : up to 54 Mbps
WiFi 4 (802.11n) : up to 450 Mbps
WiFi 4 (802.11n) (1024QAM) : up to 750 Mbps
WiFi 5 (802.11ac) (1024QAM) : up to 4333 Mbps
WiFi 6 (802.11ax) (2.4GHz) : up to 861 Mbps
WiFi 6 (802.11ax) (5GHz) : up to 4804 Mbps Antenna
External antenna x 3
Internal PCB antenna x 1 Transmit/Receive
2.4GHz 3x3
5GHz 4x4 Processor
RT-AX86U:1.8GHz quad-core processor Memory
RT-AX86U: 256 MB Flash
1 GB RAM Boosts speed
OFDMA (Orthogonal Frequency Division Multiple Access)
Beamforming: standard-based and universal
1024-QAM high data rate
20/40/80/160 MHz bandwidth Operating Frequency
2.4 GHz / 5 GHz Ports
RT-AX86U:
RJ45 for 10/100/1000 BaseT for WAN x 1
RJ45 for 10/100/1000 BaseT for LAN x 4
Five (5) 10/100/1000 Mbps Gigabit Ethernet ports + one (1)
2.5G/1Gbps multi-Gig port (configurable)
-- LAN: 4xGbE (2x port aggregation LAN)
-- WAN: 1 GbE
-- WAN/LAN: 2.5G/1Gbps multi-Gig port (configurable)
-- Multi-Gig: Ability to aggregate two Gigabit LAN ports and two Gigabit WAN ports (configurable) concurrently.
USB 3.2 Gen 1 x 2 Button
WPS Button, Reset Button, Power Switch, LED on/off ButtonLED Indicator
RT-AX86U:
Power x 1
2.4GHz x 1
5GHz x 1
2.5G Port x 1
WAN x 1
LAN x 4
WPS x 1 Power Supply
AC Input : 110V to 240V(50 to 60Hz)
DC Output : 19 V with max. 2.37 A current / 19.5 V with max. 2.31 A current/ 12 V with max.3 A current Package content
RT-AX86U WiFi router
RJ-45 cable
Power adapter
Quick Start Guide
Warranty card AiMesh
AiMesh : Yes
Primary AiMesh router : Yes
AiMesh node : Yes Router APP
ASUS Router APP : Yes Game
Game Boost/acceleration : Yes
WTFast : No Alexa
Support Alexa skil : Yes IFTTT
Support IFTTT : No

Package Contents:

• RT-AX86U Wireless Router
• RJ-45 Cable
• Power Adapter
• Quick Start Guide
• Warranty Card
