Intel RealSense D415 Webcam - 30 fps - USB 3.0 (82635asrcdvkhv)
(No reviews yet)
Write a Review
- SKU:
- 18157578
- MPN:
- 82635asrcdvkhv
- Availability:
- Usually ships the same or next business day. In stock at our CA, IL, PA warehouses.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 05/17/2024 12:13:40 AM PST
Bulk discount rates
Below are the available bulk discount rates for each individual item when you purchase a certain amount
| Buy 3 or above | and pay only $265.93 each 265.93 |
- Stock Update:
- 05/17/2024 12:13:40 AM PST
Description
This item is brand-new, factory sealed.
The Intel RealSense Depth Camera D400 Series uses stereo vision to calculate depth. The D415 is a USB-powered depth camera and consists of a pair of depth sensors, RGB sensor, and infrared projector. It is ideal for makers and developers to add depth perception capability to their prototype development.The depth camera includes:
A powerful vision processor that uses 28 nanometer (nm) process technology and supports up to 5 MIPI Camera Serial Interface 2 lanes to compute real-time depth images and accelerate output.
New advanced stereo depth algorithm for accurate depth perception and long range.
A set of image sensors that enable capturing of disparity between images up to 1280 x 720 resolution.
Support for the cross-platform, open-source Intel RealSense SDK 2.0.
Dedicated color image signal processor for image adjustments and scaling color data.
Active infrared projector to illuminate objects to enhance the depth data.
Intel RealSense Depth Camera D415 is designed to best fit your prototype. With the rolling image shutter and narrow field of view (69.4 x 42.5 x 77), Intel RealSense Depth Camera D415 offers high depth resolution when object size is small and more precise measurements are required.
Use Environment
Indoor/Outdoor Depth Technology
Active IR stereo Main Intel RealSenseTM component
- Intel RealSenseTM Vision Processor D4
- Intel RealSenseTM module D410
Depth Field of View (FOV) (Horizontal x Vertical x Diagonal)
65o+/-2o x 40o+/-1o x 72o+/-2o Depth Stream Output Resolution
Up to 1280 x 720 Depth Stream Output Frame Rate
Up to 90 fps Minimum Depth Distance (Min-Z)
0.3 m Sensor Shutter Type
Rolling Shutter Maximum Range
Approx. 10 meters, Varies depending on calibration, scene, and lighting condition RGB Sensor Resolution and Frame Rate
1920 x 1080 at 30 fps RGB Sensor FOV (Horizontal x Vertical x Diagonal)
69.4o x 42.5o x 77o (+/- 3o) Connectors
USB-C 3.1 Gen 1 Mounting Mechanism
- One 1/4-20 UNC thread mounting point
- Two M3 thread mounting points
Item Dimension (L"x W"x H")
11 x 6 x 5
Weight
3.00 LB
Warranty Information
1-years limited
Specs
| Physical Characteristics | |
| Height | 0.9" |
| Width | 3.9" |
| Depth | 0.8" |
| Warranty | |
| Limited Warranty | 1 Year |
| Interfaces/Ports | |
| Host Interface | USB 3.0 |
| Display & Graphics | |
| Maximum Frame Rate | 30 fps |
| Maximum Video Resolution | 1920 x 1080 |
| General Information | |
| Brand Name | Intel |
| Manufacturer Website Address | http://www.intel.com |
| Marketing Information | Depth Camera D415 The Intel® RealSense™ D415 has a standard field of view well suited for high accuracy applications such as 3D scanning. With a rolling shutter on the depth sensor, the D415 offers our highest depth quality per degree. Precision and Accuracy When accuracy is the most important factor for your solution, the D415 is the perfect choice. The D415 has a tightly focused field of view, which offers higher quality depth per degree. Featuring an integrated RGB sensor, the D415 is perfect for facial authentication, 3D scanning or volumetric capture. Ideal for Development & Productization With the Intel® RealSense™ depth camera D415, Intel maintains its track record of bringing exciting new vision sensing products to market. This camera puts an Intel module and vision processor into a small form factor ideal for development and productization. Lightweight, powerful, and low-cost, it pairs with customizable software to enable a one-stop shop for assembly and creation of a new generation of sensing solutions and devices that are better able understand and interact with their surroundings. Ideal for Precise Measurement The D415 has a standard field of view and uses rolling shutter sensors. This field of view results in higher depth resolution for smaller objects or when more precise measurements are required. The rolling shutter sensors and smaller lenses allow for a lower cost, yet highly capable depth camera. |
| Product Type | Webcam |
| Product Name | RealSense Depth Camera D415 |
| Manufacturer | Intel Corporation |
| Manufacturer Part Number | 82635ASRCDVKHV |
| Product Model | D415 |
| Product Line | RealSense |
Warranty Information
All Items are Brand New, Factory Sealed and come with a standard warranty. [Read our policies]
View AllClose
Intel RealSense D415 Webcam - 30 fps - USB 3.0 (82635asrcdvkhv)
$275.47
